HOT Selling Factory Price Gear Hobbing Machine /Gear Hobber
- 3500.00 set
| Certification: | CE,TUV,SGS; | model: | HT-GC500; |
| Weight (KG): | 3300; | Brand Name: | HENTO; |
| Product type: | Gear Hobbing Machine; | size: | 2290*1100*1910; |
| Power (kW): | on the specification; | Dimension(L*W*H): | 2290*1100*1910; |
| Packaging Detail: | Fumigation-free wooden case Gear Hobbing Machine; | Condition: | New; |
| Name: | Gear Hobbing Machine; | certifciate: | CE,TUV,SGS; |
| COLOR: | Customers' Require; | Payment Terms: | L/C,T/T,Western Union,MoneyGram,Gear Hobbing Machine; |
| CNC or Not: | Normal; | Applicable Industries: | Building Material Shops,Machinery Repair Shops,Retail,Gear Hobbing Machine; |
| Voltage: | 380V; | Type: | Gear Grinding Machine; |
| weight: | 3300KG; | voltage: | 380V; |
| Port: | Qingdao,Shanghai or as customers' request; | Supply Ability: | 150 Set/Sets per Month Gear Hobbing Machine; |
| Key Selling Points: | Automatic; | Warranty: | 2 years,2 years; |
| After-sales Service Provided: | Online support,Video technical support,Engineers available to service machinery overseas; | Place of Origin: | China; |
HOT Selling Factory Price Gear Hobbing Machine /Gear Hobber
*The machines permit cutting by climbing hobbing method, in addition to conventional hobbing method, to raise the productivity of the machines.
*A rapid traverse device of hob slide and an automatic shop mechanism are provided on the machines allowing several machines to be handled by one operator.
*The machines are easy in operation and convenient to be maintained.
Main technical parameters | HT-GC500 | ||
Max working module | steel | 6 | |
Cast iron | 8 | ||
Max diameter of cutting cylindrical straight gear | with trestle (mm) | 450 | |
without trestle(mm) | 800 | ||
Max diameter of cutting Cylindrical helical gear
| Rotation angle 30° | 500mm | |
Rotation angle 60° | 190mm | ||
The changeable spindle diameter of of hob (mm) | 22 27 32 | ||
The travel length of hob axial movement(mm) | 30 | ||
The travel length of rear pillar movable trestle | 200 | ||
Diameter of workingtable hole (mm) | 80 | ||
Diameter of worktable axis(mm) | 35 | ||
Pitch diameter of indexing wormwheel (mm) | 546 | ||
Pitch diameter of indexing worm (mm) | 68 | ||
Speed of Hob main spindle | Grade | 7 | |
Range (r/min) | 47.5-192 r/min | ||
The workpiece vertical feed | 0.25-3 mm/r | ||
Main motor power | 3 kw | ||
Main motor speed | 1420 r/min | ||
Net weight | 3300 kg | ||
Size (L*W*H)(mm) | 2290*1100*1910 | ||
If you need further information, please contact us freely, we will do our best to cooperate with you.
