Wholesale custom printed circuit board layout factory price high frequency design pcb gerber file schematic schematic services
-
Supplier: Jinhua Technology (Shenzhen) Co., Ltd. -
Region: Guangdong, China -
Contact: Ms Rosia Cao -
Price: $3.90 / 1 - 999 pieces
$1.90 / 1000 - 2999 pieces
$0.90 / 3000 - 4999 pieces
$0.10 / >=5000 pieces -
Min. Order: 1 piece
Product details
| Plate thickness: | 1.5mm | Surface treatment: | ENIG |
| Serve: | Provide OEM service | model: | JH-HFPCB-035 |
| Testing service: | 100% electronically tested | Copper thickness: | 1 oz |
| Origin: | Guangdong, China | Substrate: | Rogers/Taconic/Arlon |
| layer: | 1~20 floors | Board Dimensions: | 100*200mm, or can be customized |
| brand: | Jinhua | Minute line spacing: | 3000000 |
| product name: | High frequency circuit board | port: | Shenzhen |
| Supply capacity: | 50000 pieces per month | MOQ: | 1 item |
| type: | High frequency circuit board | payment terms: | L/C, Western Union, D/P, D/A, T/T, MoneyGram |
| application: | electronic product | Minute Hole Size: | 0.15mm |
| Key words: | circuit board design | Package preview: | |
| Minute line width: | 3000000 | Certificate: | ISO9001/Iso14001/CE/ROHS |
| Printed Circuit Board Standards: | IPC-A-610D/IPC-III | custom made: | Rogers PCB Fabricator Available |
| Packaging Details: | Bubble bag, pearl cotton bag, anti-static bag, vacuum bag |
Important factors for high frequency boards
Dielectric constant (DK)
Dissipation factor (DF)
Thermal expansion coefficient
hygroscopicity
Product Description
| High frequency PCB function | ||
| thing | content | ability |
| 1 | Quality Standard | UL94V.0, IPC-6012, 6013, ISO-9001, ISO-14001 |
| 2 | layers | 2-24L |
| 3 | delivery time | 5 days - 3 weeks |
| 4 | Material | RO4003C, RO4350B, RO3003, RO3010, RO3210, RT5880 |
| 5 | Polypropylene | Rogers 4450F, Domestic-(25FR), Domestic-(RF-27), Domestic-(6700) |
| 6 | Board Dimensions (Min-Max) | 10mm*10mm to 450mm*610mm |
| 7 | Plate thickness (min-max) | 0.4mm-5.0mm |
| 8 | Copper Thickness (Min-Max) | 0.5oz-2oz |
| 9 | Line Width/Space (Minimum) | 3/3 million |
| 10 | impedance | +/-10% |
| 11 | Minimum drilling diameter | 0.15mm |
| 12 | surface treatment | ENIG, immersion tin, immersion silver, OSP |
| 13 | other technologies | Strippable solder mask, gold finger, carbon oil, countersink, back drill |
Main application of high frequency PCB:
