Factory wholesale hn-85 analog 0-30a ac/dc ammeter and dv/av voltmeter analog panel meter

Product details
Place of Origin:Shanghai China;Brand Name:AOYI;
Attachment:shunt/constant resistor;Dimensions:60*70;
Accuracy Class:2.5;Payment Terms:L/C,Western Union,T/T,Paypal;
Supply Ability:1000000 Unit/Units per Month;Port:Shanghai or Designated Port;
Measuring Range:0-50A, 1-600V;Measuring Range:0-15A;
Supply Voltage:0-600V;size:60*70;
Packaging Detail:Standard export color box for analog volt meter;Display Type:Analog Only;
Operating Temperature:-20-50degree;Color:Black and White;
Model Number:HN-85;Use:current meter/voltage meter/factor meter/frequency;
Accessories



Product Description



HN-85  Panel Meter Analog 0-30A DC Amp meter



Product Description

Composition:

PC Front and Bakelite case, Four stud mounting,



Scale Plate:

The normal scale plate is made of alloy-aluminium material white printed with black scales,Values, units, technique symbols, etc.

Scale plate with special requirements are available upon request.

Such as color



Color:

Black case, white scale plate.



Pointer:

Normally, the pointer is made of alloy-aluminium, it is black, and red, white are available Upon request.



Anti-static:

All meters are subject to anti-static treatment to minimize the static-effect to the accuracy of  the meters.



Damping and Overshoot:

The overshoot is less than 15% when the pointer is at the 2/3 of the scale.

Damping and overshoot can be customized according to user’s requirements.



Service condition:

-20~+40 degree;



Operating position:

Generally, meter is installed in vertical position. Other installation position can be customized (please specify the desired angle).The accuracy class is just valid for the Corresponding installation mode.



Insulation Test:

The test Voltage for BE&BP series is 2KV RMS for 1 minute with the frequency 50Hz.



Safety Precautions:

Meters with damaged bezels or glass faceplates must be disconnected from the mains. Scale plate, front frames and windows may only be replaced under voltage-free conditions.

The meter should be kept clean, if the meter is used in a manner not specified by the manufacturer, the protective function may be impaired.



The advantages of Our products:

Interchangeable Dial.

Changing the scale plate without opening the meter.Under the same secondary current, the scale plate of AC ammeter can be Changed, no loss of accuracy.



HN-85  Panel Meter Analog 0-30A DC Amp meter



Current

Ranges





mA

4-20mA 1mA 10mA 500mA

A

0.5A -50A

For connecting to external shunt

50mV

60mV 75mV

10A -3000A

Voltage

Ranges

V

Range :10V 25V 40V 50V 60V 100V 150V 250V 300V 450V 500V 600V



Dimensioned drawing:

product recommendati

Company Information



Certifications



Packaging & Shipping



FAQ

1. Q: Can you provide OEM service?

    A: Yes, we can.

2. Q: What's the MOQ?

    A: For testing purpose, 1pc is ok.

3. Q: Can you provide trade assurance service?

    A: Yes, we are member of the Alibaba trade assurance scheme.

4. Q: What's the lead time?

    A: General lead time is 15 days after payment.

5. Q: What's your waranty?

    A: We provide 12 months warranty against manufacturing defective.
