Timing indicator watch moving iron analog watch long scale analog panel watch-everfar

work:
Includes glass window, ABS resin frame and casing, PC fiberglass base mounting hardware.

Dial:
Ordinary dials are made of alloy aluminum, with black scales, values, units, technical symbols, etc. printed on white.
Dials for special requirements are available upon request.
Such as color, scale with illuminated function and PVC luminous are available upon request.

color:
Black base and frame, white dial and body.

pointer:
Usually, the hands are made of aluminum alloy and are black, red and white are also available upon request.

anti-static:
All meters are anti-static to minimize the impact of static electricity on meter accuracy.

Damping and Overshoot:
When the pointer is at 2/3 of the scale, the overshoot is less than 15%.
Damping and overshoot can be customized according to user requirements.

accuracy:
Class1.5, 2.5;

Service conditions:
-20 +55 degrees;

Operating position:
The instrument is generally installed vertically. Other installation positions can be customized (please specify the required angle). The accuracy level is only valid for the corresponding installation method.

Insulation test:
The test voltage is 2KV RMS for 1 minute and the frequency is 50Hz.

Safety Instructions:
Instruments with damaged bezels or glass panels must be disconnected from the power supply. Scale plates, front frames and windows can only be replaced under voltage-free conditions.
The meter should be kept clean, if the meter is used in a manner not specified by the manufacturer, the protection may be impaired.

Advantages of our products:
Interchangeable dials.
The dial can be changed without opening the watch. In the case of the same secondary current, the dial of the AC ammeter can be replaced without loss of accuracy.
