2018 Digital DC Nano Ammeter with stable performance

Supplier: Biobase Meihua Trading Co., Ltd.
Region: Shandong, China
Contact: Mr Jeffrey Xue
Price: $50.00 /unit
Min. Order: 1 unit

Click here to contact

Product details

Range:	AC 10mA~10A(7 Steps);	Place of Origin:	Shandong China;
Operating Temperature:	0~40;	Accuracy:	1.5%(DC), 2%(AC);
Fuse:	1A and 10A;	Display Type:	Digital Only;
Function:	AC/DC Current meter;	Operating frequency:	45~400Hz;
Dimensions:	AC 10mA~10A;	Accessories:	N/A;
Brand Name:	BIOBASE;	Packaging Detail:	carbon package;
Payment Terms:	L/C,T/T,Western Union;	Measuring Range:	0~9999;
Port:	qingdao;	Delivery Detail:	7-15 DAYS;
Accuracy Class:	0.5;	Supply Ability:	100 Unit/Units per Day;
Supply Voltage:	DC4.5-30V;	Model Number:	BK-MS301;

Digital DC Nano Ammeter

Product Description

Features:

1.Sturdy, simple and extremely safe to use
2.High accuracy and reliability
3.Combination of electonic and mechanical advantage
4.Single switch for range selection
5.Safety sockets and dual insulation
6.Moulded, water-resistant casing

Technical Parameters:

Model	BK-MS301	BK-MS302	BK-MS303
Function	AC/DC Current meter	AC/DCVoltage meter	Galvano meter
Range	AC 10mA~10A(7 Steps) DC 100uA~10A(11 Steps)	AC 3V~1000V(6 Steps) DC 100mV~1000V(8 Steps)	DC 30uA~3mA(2 Steps) DC 100mV(1 Steps for shunts)
Accuracy	1.5%(DC), 2%(AC)	1.5%(DC), 2%(AC)	1.5%
Operating frequency	45~400Hz	20~400Hz
Fuse	1A and 10A	Electronic protection	200mA
Accessories	N/A	N/A	N/A
Model	BK-MS304	BK-MS305	BK-MS306
Function	Single phase wattmeter	Single and 3-phase wattmeter	Multi- meter
Range	AC/DC 60-120-240-480V AC/DC 0.5A/1A	AC/DC 60-120-180- 240-360-480V(1Ph.) AC/DC60√3-120√3-180√3-240√3V(3 Ph.)	DCV 2.5V~1000V(7 Steps) ACV 10V~1000V(6 Steps) DCA 50uA~10A(9 Steps) ACA2.5mA~10A(7Steps) Resistance 1Ω~1kΩ(4 Steps)
Accuracy	2.5%(DC), 1%(AC)	2.5%(DC),1%(AC 1 Ph.), 2%(AC 3 Ph.)	1.5%(DC), 2.5%(AC)
Operating frequency	0~500Hz	15~500Hz	20~400Hz
Fuse	1A	5A	10A and 1A
Accessories	N/A	N/A	Test leads X 2
