DN50 Water flow sensor 2-inch turbo large flow 10-300L/min large flow DN40 Industrial agricultural Flowmeter

Supplier: Shenzhen Guangfasheng Technology Co., Ltd.
Region: Guangdong, China
Contact: Ms Anne Zhai
Price: $1.00 /piece
Min. Order: 1 piece

Click here to contact

Product details

Operating voltage Range:	DC 5~18v;	Flow Range:	10~300L/min±3%;
Insulation resistance:	>100MΩ;	Material:	ABS Material;
Water resistant:	lower 1.75MPa;	Brand Name:	Original;
Payment Terms:	T/T,Western Union,Paypal;	Place of Origin:	Guangdong China;
Application:	Industrial agricultural Flowmeter;	Model Number:	DN50/40;
Flow Pulse characteristics:	f(Hz)=[ 0.2* Q ] ±2%;	Skype/Wechat:	gfsic02;
Product Name:	water flow sensor;	Connection:	DN50/40;
Port:	Shenzhen;	Packaging Detail:	standard carton package;
Supply Ability:	100000 Piece/Pieces per Day;

DN50 Water flow sensor 2-inch turbo large flow 10-300L/min large flow DN40 Industrial agricultural Flowmeter

Product Description

Product Features:
1. The appearance of this product is lightweight and clever, small size, easy to install.
2. The impeller is fitted with stainless steel beads, always wear-resistant.
3. The sealing ring is used, and the structure of the lower force never leaks.
4. Hall components are imported from Germany and encapsulated with sealant,
Prevent water, never aging.
5. All raw materials are in compliance with ROSH testing standards
The product brief introduction:
The water flow sensor is mainly composed of plastic valve body, water flow rotor assembly and Hall sensor.
It is installed at the inlet end of the water heater and is used to detect inlet flow, and when water passes through the flow rotor assembly,
The magnetic rotor rotates and the rotational speed changes with the flow rate, and the hall sensor outputs the corresponding pulse
Signal, feedback to the controller, by the controller to judge the size of water flow, to regulate.
Precautions for use
Severe shocks and the erosion of chemical substances are strictly prohibited. Throwing or colliding is strictly prohibited.
Installation direction diagram
Horizontal or vertical mounting is possible.
The media temperature should not exceed 120°.
