oem odm pcba prototyping pcb assembly board factory Wifi Sensor Ble high quality

Product details
product name:Wifi/BLE Sensor PCBA AssemblySolder mask:green. Red. blue. white. black.yellow
Copper Thickness:1OZ-3OZPackaging Details:Neutral packing
Plate thickness:0.8-16mmPackaging Preview:
place of origin; place of origin:Chinaport:Hong Kong/Shenzhen
application:smart homeFloor:1-18 floors
SMT efficiency:BGA.QFP.SOP.QFN.PLCC.CHIPFunction:Smart Home Control
Surface treatment:Immersion Gold (ENIG)Substrate:FR4 CEM1 CEM3 High Thermogravimetric
payment terms:L/C,D/A,D/P,T/T,Western Union,MoneyGram,Paypalmodel:MK1228
PCBA service:Turnkey Assembly PCBA ServiceSupply capacity:10,000 OEM/ODM services per day
Test service:AOI X-ray Functional Testminute. Line spacing:0.10mm
minute. Line width:0.10mmminute. Hole size:0.2mm
brand:OEM ODMPrinted circuit board standard:IPC-A-610E


oem odm pcba prototyping pcb assembly board factory high quality Wifi Ble sensor


welcome to moco


MOKO TECHNOLOGY LTD was established in 2006, located in Shenzhen, as a professional EMS/OEM manufacturer, can provide one-stop pcb assembly service, we can also provide:


- contract drafting (noun

- engineering service

- PCB Assembly

- Component procurement and material management

- Rapid prototyping

- Cables and wire assemblies

- Plastics and moulds

- Functional testing service


As a professional PCB assembly and PCB manufacturer in China, we pride ourselves on excellent customer service and reliability! MOKO Technology Ltd also provides exclusive services to help our clients with PCB projects.




our service


Our PCB Services:

1. PCB manufacturing.

2. Turnkey PCBA: PCB+Components+SMT and Through Hole Assembly+Shell Forming & Shell


Our advantage:

1. Free programming and free functional testing, free packaging.

2. High quality: IPC-A-610E standard, E-test, X-ray, AOI test, QC, 100% functional test.

3. Professional services. ISO SMT and through-hole assembly, over 10 years of experience.

4. Electronic product certification: 94v-0, CE, SGS, FCC, RoHS, ISO9001:2008, ISO14001

5. PCBA warranty period: 2 years.


Turnkey PCBA PCB + component procurement + assembly + packaging
Assembly Details SMT and Through Hole, ISO SMT and DIP Lines
delivery time Prototype: 15 working days. Large order: 20~25 working days
product testing Flying probe test, X-ray inspection, AOI test, functional test
quantity Minimum quantity: 1 piece. Prototype, small order, large order, all OK
needed file PCB: Gerber files (CAM, PCB, PCBDOC)
Components: Bill of Materials (BOM)
Assembly: Pick-N-Place File
PCB panel size Minimum size: 0.25*0.25 inches (6*6mm)
Maximum size: 20*20 inches (500*500mm)
PCB Soldering Type Water-soluble solder paste, RoHS lead-free
Component details Passive down to 0201 size
Leadless Chip Carrier/CSP
Double Sided SMT Assembly
Fine pitch to 0.8 mil
BGA Repair and Reball
Parts removal and replacement
component package Cutting tape, tubing, reels, loose parts
PCB Assembly
Drilling-----Exposure-----Plating-----Etching and Stripping-----Stamping-----Electrical Testing-----SMT-----Wave Soldering-- - --Assembly-----ICT-----Functional Test-----Temperature and Humidity Test
