ACREL ammeter PZ72L-DI dc current meter/LCD display amp amperometer digital panel meter 0-9999A

Supplier: Acrel Electric Co., Ltd.
Region: Shanghai, China
Contact: Ms Connie Wang
Price: $44.80 /piece
Min. Order: 1 piece

Click here to contact

Product details

Selling Units:	Single item;	Display Type:	Digital Only;
Option function:	rs485/DI/DO/analog output;	Model Number:	PZ72L-DI;
Measuring Current Range:	4-20mA or shunt 75mV or hall component;	Measuring Range:	0~9999A;
Single package size:	24X16X14 cm;	Outline size:	757598mm;
Supply Voltage:	AC/DC85V~265V or DC24V;	Accuracy Class:	Class 0.5;
Package Type:	Packed by case. Shock bubble film.;	Operating Temperature:	-10~+55;
Single gross weight:	0.45 KG;	Professional manufacture:	15 Years;
Package Preview:	https://sc02.alicdn.com/kf/ULB8jS1bmv2JXKJkSanr7613lVXa5.png_640x640.png;	Brand Name:	ACREL;
Delivery Detail:	0 days after payment;	Dimensions:	cutout 67*67mm;
Frequency:	45~65HZ;	Place of Origin:	Shanghai China (Mainland);
Display:	LCD Digital Display;

Product Description

PZ series DC current and voltage meters

PZ series DC analyzer is designed for application in direct current cabinet,solar power supply,telecom station .It can measure dc voltage, dc current of DC system. It can be used for local display and connected with the control equipment to regroup measuring and controlling system.
It can be equipped RS485 communication under Modbus-RTU protocol; and it has options of analog output, relay alarm, switch state. According to different request, meter's parameters can be set by keys on its panel.

Product Name	Function Description	unit piece (F.O.B)	Wholesale price
PZ72L-DI	LCD display, DC programmable ammete	44.8	Please contact us in detail. We can offer you the best price.
PZ72L-DI/C	LCD display, DC programmable ammete /C: RS485 Communication(Modbus-RTU)	51.1
PZ72L-DI/MC	LCD display, DC programmable ammete /C: RS485 Communication(Modbus-RTU) /M: one analog output(programmable 4-20mA)	57.4
PZ72L-DI/KC	LCD display, DC programmable ammete /C: RS485 Communication(Modbus-RTU) /K: 2DI/2DO	55.3
PZ72L-DI/JC	LCD display, DC programmable ammete /C: RS485 Communication(Modbus-RTU) /J: Alarm (over current)	55.3

Skype/Whatsapp: +8613917887510

Products Show

Other Size

Our Company

Factory

Workshop

Warehouse

Team

Packing & Delivery

Packing Details : Packed by case. Shock bubble film

Delivery Details : 5-30 days after parameters confirmed.

1. Shock bubble film

2. Packed by case.

3. International logistics company

Our Certifications

Quality is absolutely guaranteed, the wholesale price is reasonable, a large quantity of favorably.

Project Performance

Russian MMK steel mill

Adopt ACR, PZ series multifunction power meters and AKH series current transformer 1251 sets.

Costa Rica National Stadium

Adopt ACR and BD series multifunction power meters and transmitters are used in 1067 sets.

FAQ

Q: Are you trading company or manufacturer ?

A: We are factory.

Q: How long is your delivery time?

A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, according to quantity.

Q: Do you provide samples ? is it free or extra ?

A: Yes, we could offer the sample for lower price. If you place the order, all or part of the sample charge will be deducted from the goods.

Q: What is your terms of payment ?

A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
If you have another question, pls feel free to contact us as below:

Skype/Whatsapp: +8613917887510
