Hydraulic Statical Pile Drivers Piling Machine JBY-80

Supplier: Shanghai Vostosun Industrial Co., Ltd.
Region: Shanghai, China
Contact: Ms Wang Jing
Price: $61470.00 /set
Min. Order: 1 set

Click here to contact

Product details

After-sales Service Provided:	Video technical support,Online support,Free spare parts,Field installation, commissioning and training,Field maintenance and repair service;	Packaging Detail:	...;
Condition:	New;	Max. drilling depth:	20m;
Payment Terms:	L/C,T/T;	Motor power:	22kW;
UNIQUE SELLING POINT:	-;	Brand Name:	VOSTOSUN;
Local Service Location:	Egypt,Canada,Turkey,Italy,France,Viet Nam,Philippines,Brazil,Peru,Saudi Arabia,Indonesia,Pakistan,India,Mexico,Russia,Spain,Thailand,Japan,Malaysia,Australia,Morocco,Kenya,Argentina,Chile,UAE,Colombia,Algeria,Sri Lanka,Romania,Bangladesh,South Africa,Kazakhstan,Ukraine,Kyrgyzstan,Nigeria,Uzbekistan,Tajikistan;	Applicable Industries:	Building Material Shops,Machinery Repair Shops,Manufacturing Plant,Construction works ;
Showroom Location:	None;	Place of Origin:	China;
Machine weight:	58t;	Warranty:	1 year;
Platform rotary angle:	0-360;	System control:	Hydraulic control;

Product Description

Item				Unit	Model JBY62	Model JBY80
System control					Hydraulic control	Hydraulic control
Pillar support					3 support	3 support
Pillar height				m	22.5	22.5
Pillar diameter ΦS				mm	630	630
Pillar track dimension and space				mm	330XΦ70/600XΦ102	330XΦ70/600XΦ102
Pillar gradient				°	Pitch 12°/retroverted 5°	Pitch 12°/retroverted 5°
Max. working ground gradient				°	3°	3°
Platform rotary angle				°	0-360	0-360
Platform rotary speed				°/ time	15	15
Travelling mechanism	Long boat moving speed			m/min	0-4.3	0-4.3
	Long boat pace			mm	2000	2000
	Short boat moving speed			m/min	0-4.3	0-4.3
	short boat pace			mm	600	600
	Long boat grounding intensity of pressure			MPa	0.036	0.029
	Short boat grounding intensity of pressure			MPa	0.048	0.045
Hydraulic system	Motor power			kW	22	22
Hydraulic system	Hydraulic system pressure			MPa	16	16
Max. appearance dimension	Long boat dimension ( L x W)			mm	10000X1000	12000X1200
	Short boat dimension ( L x W)			mm	3760X2000	3760X2500
	Working dimension (L x W x H)			mm	11000X6760X25000	11000X6760X25000
	Transportation dimension (L x W x H)			mm	10000X3040X2150	10000X3040X2150
Machine weight				t	58	65
Adapting to Pile Machine		Piling Hammer	Diseal Hammer		HD62 & below	HD80 & below
		Piling Hammer	Hydraulic hammer		HHP6 & below	HHP8 & below
		Vibrating hammer	Electric power		90kW & below	110kW & below
		Vibrating hammer	Hydraulic power		SV80 & below	SV100 & below
		Drilling machine	Long screw drill	mm	Φ600 & below	Φ600 & below
			Screw pile driller	mm	Φ400 & below	Φ400 & below
			Max. drilling depth	m	20	20

pile drivers

Our Service

Ø Open and transparent one-stop centralized procurement;

Ø International standard purchase supply process management;

Ø Expert technical solution for production process;

Ø Display, storage and after-sales service ;

Ø International financing and insurance.

Company Information

Why Choose Us

Ø CORE VALUE:

Integrity, Profession, Efficiency, Gratitude, and Responsibility

Ø GOAL AND VISION:

Committed To Becoming a Professional Solution Provider For Centralized Procurement And Supply Of

Engineering, Mining And Mineral Powder Processing Projects.

Ø OUR MISSION:

Your Requirements For Equipment Selection, Quality, Cost, Delivery, Risk Control And After-Sales Service,

Your Service Requirements For Overseas Markets,They Are Our Existing Value And Unremitting Pursuit!

FAQ

Q:What's your payment term?
A: We accept T/T(30% down payment and balance before shipping) and L/C mostly. But if you prefer other payment terms please contact us for further information.

Q: Whats's the warranty time?
A:From the date of shipment,1 year or 1500 working hours,whichever comes first.

Q:What`s the international project experience?
A: Kazakhstan Astana Capital Moving Projuct,
Russia Voronezh Nuclear Power Station,
Shanghai Pengxin Mining Congo(Gold) Copper Project,
Equatorial Guinea National Highway Equipment General Contracting

Q:What`s the technical support or partnership?
A: Institute of Powder Engineering, Tsinghua University.
Chinese Academy of Geological Sciences.
China Academy of Building Research

Contact Us Now!!!
