Taidacent Multi-Point Inductive Sensor Thin Membrane Smart Pressure Sensitive Insoles Foot Pressure Mat Pressure Plate Sensor
- 59.02 >=2 pieces
| Working voltage: | 3.3V; | Place of Origin: | Guangdong China; |
| Package Preview: | https://sc01.alicdn.com/kf/HTB1sTo2X_jxK1Rjy0Fnq6yBaFXaV.jpg_640x640.jpg; | Model Number: | ZNX-01; |
| Single package size: | 9X9X9 cm; | Brand Name: | Taidacent; |
| Single gross weight: | 0.2 KG; | Package Type: | box package; |
| Selling Units: | Single item; |
Taidacent Multi-Point inductive sensor thin membrane smart pressure sensitive insoles foot pressure mat pressure plate sensor
Description
| Size | 41 yards (can be customized) |
| Thickness | <0.35mm |
| Response point | <150g |
| Test voltage | typical value DC 3.3V |
| Durability | > 1 million times |
| Response time | <1ms |
| Recovery time | <15ms |
| Working temperature | -20 ° C ~ 60 ° C |
| Electromagnetic interference EMI | no generation |
| Electrostatic discharge ESD | not sensitive |
| Initial resistance | >10MΩ (no load) |
Characteristics
Light and thin
high sensitivity
long life
Waterproof and pressure sensitive dual function
Application field
ZNX-01 can be widely used in smart wearable products such as temporary pressure insole, not only has basic functions such as step counting and calorie consumption index, but also real-time monitoring including running posture, landing mode, stride frequency, touch time and touch. Gait information such as ground-to-air ratio and knee load index.
Customized solution
Can support different functional requirements
Can be used for different scenarios
Customizable development of various applications
