12MM 3MHz Ceramics Piezoelectric Ultrasonic Transducer Piezo Disc
-
Supplier: Zhejiang Jiakang Electronics Co., Ltd. -
Region: Zhejiang, China -
Contact: Ms Sally MA -
Price: $0.50 / >=100 pieces -
Min. Order: 100 pieces
| Packaging Detail: | 1000PCS/BOX; | Brand Name: | JIAKANG; |
| Diameters: | 12mm; | Shape: | Round; |
| Payment Terms: | T/T,Credit Card; | Material: | Other; |
| Frequency: | 1M; | Port: | Shanghai; |
| MOQ: | 100PCS; | Supply Ability: | 800000 Piece/Pieces per Month piezoelectric transducer; |
| Type: | Dielectric Ceramics; | Model Number: | HTCY3.00A12AD0H4-T0; |
| Product name: | Piezo Electronic Ceramic; | Place of Origin: | Zhejiang China; |
You are here:Home >> Piezoelectric UltrasonicTransducer > Piezoelectric Ultrasonic Disc>>
12MM 3MHz Ceramics Piezoelectric Ultrasonic Transducer Piezo Disc
 |
Specifications | ||
(Item) |
(Unit) |
(Standard) |
Resonant frequency (Fr) | MHz | 3.00±0.1 |
Resonant impedance (Rr) | Ω | ≤2 |
Static capacitance (C0) | pF | 1900±20% |
Electrical-mechanical coupling coefficient (Kt) |
| ≥0.42 |
Dielectric loss (tgδ) |
| ≤0.5% |
| Appearance and Dimensions |
 |
Click for more information
Click for more information
Ceramic ultrasonic transducer, the core element of ultrasonic flow meters, is a liquid-medium sensor. It can be used in liquid flow meter, or as liquid level sensor. Products are made from the piezoelectric ceramic developed by ourselves, has the advantages of better temperature stability and superior piezoelectric effect. We have been in the research and development of PZT materials and products nearly 30 years.We are director of Piezoelectric Ceramic Device Specialized Committee, in charge of drawing China’s “The 11th Five-year Plan” and “The 12th Five-year Plan” for development of piezoceramics. Chooosing us will make your developping process earlier and faster. |
Customer praise
Our products are praised by customers from different countries, and the praises are true.
Q1:Are you a manufacturer or a trading company?
A1: We have been specialized in the piezo ceramic related products manufacturing for 31 years.
Q2:Where is your factory located?
A2: Factory address: No.1188,Jiahang Road,Jiaxing City , Zhejiang Province,China.
Q3: What's your company MOQ?
A3: Small quantity also available.
Q4: What's the payment way?
A4: T/T, western union, credit card etc.
Q5: Can you send a sample for us to test ?
A5: Yes, most samples are available for free. For samples whose cost is very high, the sample fee will return back in future order.
Q6:What is your shipping way?
A6: We support DHL, UPS, FedEx, EMS.
-
