Custom Logo China Ems Oem Custom Electronic Circuit Board Supplier Inverter Charger Pcb
- 3.79 10 - 999 pieces
- 3.17 1000 - 99999 pieces
- 2.27 100000 - 9999999 pieces
- 1.19 >=10000000 pieces
Registered Supplier
Direct Contact
Inquiry via Message
Product Details
| Supply capacity: | 1,000,000 pieces per month | type: | HD Printed Circuit Board |
| model: | High Density Interconnect Circuit Board | Place of origin: | Guangdong, China |
| Special technology 1: | 1. Impedance 2. Via filling 3. PFH, back drilling 4. Mixed finish 5. Cave | Copper thickness: | 0.33 ounces ~ 2 ounces |
| Package preview: | Packaging details: | Vacuum packaging + moisture-proof + humidity card | |
| brand: | picture tube | Surface treatment: | ENIG, ENEPIG, OSP, spray tin, tin, silver |
| Plate thickness: | 0.4mm~3.0mm | Special technology 2: | 6. Radiator 7. Countersink 8. Mixed stack 9. Anylayer |
| application: | Automotive, industrial, medical, data communications, consumer | payment terms: | wire transfer |
| Board size: | 5mm~500mm | Number of layers: | 2~24L any layer |
| minute. Hole size: | 0.1 | Certificate: | RoHS/ISO9001/ISO14001 |
| minute. Line width: | 0.05mm | Serve: | OEM/design and manufacturing |
| Base material: | FR4, CEM1, PI, PET, ceramics, SUS, glass... | minute. Line spacing: | 0.05mm |
Product display
main products
Basic specifications | ||
CPU | Rockchip RK3128, quad-core ARM Cortex A7 1.3 GHz | |
graphics processor | Quad-core ARM Mali-T400 | |
Built-in storage capacity | EMMC 8GB/16G/32G optional (sample is 8GB) | |
UI | LVDS interface (dual 10-bit), maximum resolution 1920×1080; | |
Onboard backlight | 3.3V/5V/12V optional | |
network | RJ45 interface 100M, supports Ethernet | |
Bluetooth+wifi module, Wi-Fi 802.11b/g/n protocol, 2.4G, | ||
Bluetooth 4.0 protocol | ||
3G/4G data function, WCDMA, EVDO, CDMA, GSM, 2G/3G supports 850/900/1800/1900MHz/2100MHz | ||
image rotation | 0°, 90°, 180°, 270° manual rotation | |
Real Time Clock | Built-in real-time clock powered battery, supports scheduled power on and off | |
interface device | 5 USB HOSTs (3 pin headers, 2 external interfaces) | |
2 RS232 serial ports (TTL/232 optional), supports external serial device modules (extended sensors or one-dimensional barcode, barcode scanner, printer, card reader module, etc.) | ||
SD/TF card expansion, up to 64GB | ||
Class D extra large built-in speaker, 10W*2 8Ω | ||
video | 1080P decoding of H.264, VP8, RV, WMV, AVS, H.263, MPEG4 and other video formats, as well as H.265, HTML5 encoded 4K high-definition video Video playback, Flash10.1 playback | |
power supply | Input: DC12V or DC12V 5V STB (power supply) | |
Application scenarios
Automobile, industry, medical, consumer, network, communication
Number: CRT_CARPCB_V01
Prices are for reference only. Please provide PCB data or Gerber files for accurate quotation
