40*56mm solar street light pcb pcba manufacturer pcb customization

  • Supplier: Mankun Electronic Co., Ltd.
  • Region: Guangdong, China
  • Contact: Ms Belinda hu
  • Price: $0.29 / 500 - 999 pieces
    $0.26 / >=1000 pieces
  • Min. Order: 500 pieces
Click here to contact
Product details
Led pcb:Customize led pcb;Keyword 2:Pcb Printer;
Model Number:MK;Surface Finishing:osp;
Board Size:40*56mm;Base Material:aluminum;
Board Thickness:2.0mm;Other Service:One-stop PCB Assembly Service;
Silkscreen Color:Black.white;Thermal Conductivity:1.0W/m;
Min. Line Width:5mil;Service:One-stop Service;
Packaging Detail:vacuum+foam packing;Single package size:4X5.6X0.2 cm;
Place of Origin:Guangdong, China;Package Preview:;
Selling Units:Single item;Solder Mask Color:White Black Yellow Green Red;
Min. Line Spacing:5mil;Min. Hole Diameter:0.3mm;
Brand Name:mankun;Certificate:CE ROHS ISO9001;
Layer:Single Layer;Copper Thickness:35μm;
Product name:mankun;Single gross weight:0.050 KG;
assembled led pcb hasl single sided pcb inverter pcb hasl single sided pcb single pcb
Product specifications
* Substrate - Aluminum
* Type of PCB - Rigid
* Thickness - 1.6mm
* Solder Mask - White
* Silkscreen - LF HASL
* Via Process - Tenting vias
* Surface Finish - LF HASL
* Layers - 1 layer board
* Copper - 1oz Cu
* PCB size --40*56mm
* Splicing method--4*5/20pcs
* PNL size-- 278*160mm
* Vacuum Packaging
* 500PCS, Minimum packing

40*56mm product series(Floodlighting PCB)
Type
PNL size
Copper Cladding
Surface
Materials
LED Chip
15798
4*5/278*160*1.6mm
35um /1OZ
White
Aluminum 1.0W/mK
3030-6S4P
15979
4*5/278*160*1.6mm
35um /1OZ
White
Aluminum 1.0W/mK
3535-10S1P
15980
4*5/278*160*1.6mm
35um /1OZ
White
Aluminum 1.0W/mK
5050-2S5P
15981
4*5/278*160*1.6mm
35um /1OZ
White
Aluminum 1.0W/mK
3030-5S9P
15982
4*5/278*160*1.6mm
35um /1OZ
White
Aluminum 1.0W/mK
3535-6S6P
15983
4*5/278*160*1.6mm
35um /1OZ
White
Aluminum 1.0W/mK
5050-2S8P
15984
4*5/278*160*1.6mm
35um /1OZ
Black
Aluminum 1.0W/mK
3030-7S7P
15985
4*5/278*160*2.0mm
35um /1OZ
White
Aluminum 1.0W/mK
philips3030-5S9P
15986
4*5/278*160*1.6mm
35um /1OZ
White
Aluminum 1.0W/mK
OSRAM 3030-5S9P
15987
4*5/278*160*1.6mm
35um /1OZ
Black
Aluminum 1.0W/mK
CREE 3030-7S7P
15988
4*5/278*160*2.0mm
35um /1OZ
Black
Aluminum 2.0W/mK
philips3030-7S7P
15989
4*5/278*160*1.6mm
35um /1OZ
White
Aluminum 1.0W/mK
OSRAM3030-7S7P
15990
4*5/278*160*1.6mm
35um /1OZ
White
Aluminum 1.0W/mK
CREE3030-7S7P
15991
4*5/278*160*1.6mm
35um /1OZ
White
Aluminum 1.0W/mK
5050-10S1P
15992
4*5/278*160*1.6mm
35um /1OZ
White
Aluminum 1.0W/mK
5050-1S16P
16466
4*5/278*160*1.6mm
35um /1OZ
White
Aluminum 1.0W/mK
2835-5S6P

All the PCB can be customized in materials,
size, shape and so on.

PROTOTYPES,
WE OFFER,
No MOQ
Shipment in 2 weeks
Customized design
Rebate on high VOLUME ORDERS



Lead time:
Pcb production time =Sample:3-4days mass production:7-8 working days
Pcb assembly time= sample:1-2days mass production:3-4days
Remark :mass production exact delievry time depends on the quantity.

Can I Have Details of this Product?
Yes, Common Data are in the Following Table.
Technical parameters and process capability of metal substarte(MCPCB)
ITEM
SPECIFICATION
Surface
LF HASL,immersion gold,immersion siliver,OSP
Layer
Single side,double sided Multilayer and special structure
Maximum PCB size
240mmx1490mm OR 490x1190mm
PCB thickness
0.4-3.0mm
Copper Foil thickness
H 1/2/3/4(oz)
Insulation layer thickness
50/75/100/125/150/175/200(um)
Metal Base thickness
AIuminum(1100/3003/5052/6061),Copper AIuminum
Metal Base thickness
0.5/0.8/1.0/1.2/1.6/2.0/3.2/5.0(mm)
Shaping
Die punching/CNC Route/V-Cut
Test
100% open&short test
Shaping tolerance
Die Punching<+- 0.05mm,CNC Route<+-0.15mm,V-CUT Thick residue>+-0.15mm
Hole tolerance
+-0.5mm
Min.Hole DIameter
Single side 0.5/Double sided PTH0.3MM
Solder mask
green/white/black/red/yellow
Min.letter height
0.8mm
Min.line space
0.15mm
Min.letter width
0.15mm
Sile screen color
blue/white/black/red/yellow
Sopecial hole
Spot facing/cup hole/buried via hole/buried tank
File format
Gerber,Protel,PowerPCB,AutoCAD etc
FAQ
Q: 1. CAN I HAVE A SAMPLE ?

A: YES, WE CAN SEND YOU OUR SAMPLE TO CHECK OUR QUALITY.

Q: 2. WHAT IS THE LEAD TIME?

A:SAMPLE NEEDS 1- 3 working DAYS, MASS PRODUCTION NEEDS 7-10 DAYS, ALSO ACCORDING TO THE ORDER VOLUME.

Q: 3. DO YOU HAVE ANY MOQ LIMIT?

A: OUR MOQ IS 1PCS.

Q: 4. CAN YOU OFFER BEST PRICE TO US?

A: YES, WE ARE A MANUFACTORY , SO WE CAN OFFER LOW PRICE THAN THE TRADING COMPANY.

Q: 5. HOW DO YOU SHIP THE GOODS AND HOW LONG DOES IT TAKE ARRIVE?

A: WE USUALLY SHIP BY DHL, UPS, FEDEX OR TNT. IT USUALLY TAKES 3-5 DAYS TO ARRIVE.

Q: 6. WHAT FILE WE SHOULD OFFER?

A: MAKING PCB SHOULD OFFER GERBER FILE (PROTEL ,POWER PCB,PADS FILE), PCBA SHOULD OFFER GERBER FILE AND BOM LIST.

Q: 7. WE WANT TO VISIT YOUR COMPANY?

A: NO PROBLEM, WE ARE A PRODUCTION AND PROCESSING ENTERPRISES, LOOK FORWARD TO YOUR ARRIVAL AND WE WILL LEAD YOU TO VISIT OUR
FACTORY AND PROCESSING FACTORY.

Contact person:Celio Phone:18922313080
Tel:86-020-34832899 Skype:sales3@mankun.net
VIEW MORE
