China Factory Outlet Best Horizontal Metal Automatic CNC Lathe Machine with Nice Price

Supplier: Almaco Machine Tool Co., Ltd.
Region: Jiangsu, China
Contact: Mr Bill Jin
Price: $6572.00 /set
Min. Order: 1 set

Click here to contact

Product details

Max. Length of Workpiece (mm):	2000 mm;	Precision:	High Precision;
Video outgoing-inspection:	Provided;	Year:	2021;
Package:	wooden case;	Model Number:	LFNC7525;
Positioning Accuracy (mm):	±0.001;	Core Components:	Motor,PLC,Gearbox;
Structure:	Flat Bed Lathe;	Payment Terms:	L/C,D/P,D/A,T/T;
CNC Control System:	GSK;	Certification:	CE;ISO9001;
Key Selling Points:	Competitive Price;	Weight (KG):	3500;
Process Usage:	Metal-Cutting CNC Machine Tools;	Warranty of core components:	1 Year;
Place of Origin:	Jiangsu China;	Warranty:	1 Year;
Repeatability (X/Y/Z) (mm):	±0.005;	Packaging Detail:	Standard packing;
Applicable Industries:	Building Material Shops,Machinery Repair Shops,Manufacturing Plant,Restaurant,Printing Shops;	Automatic Grade:	Automatic;
Machinery Test Report:	Provided;	name:	china best cnc lathe;
Marketing Type:	New Product 2020;	Local Service Location:	Egypt,Canada,Algeria;
Type:	Horizontal;	After Warranty Service:	Video technical support,Online support,Spare parts,Field maintenance and repair service;
Color:	Custom-made;	No. of Spindles:	2;
After-sales Service Provided:	Engineers available to service machinery overseas,Online support,Video technical support,Free spare parts,Field installation, commissioning and training,Field maintenance and repair service;	Turret Type:	4/6/8 Station Electric Turret;
Number of Axes:	2;	CNC or Not:	CNC;
Condition:	New;	Spindle Motor Power(kW):	11;
Voltage:	380V;	Showroom Location:	Egypt,Canada,Algeria;
Port:	Shanghai;	Spindle Bore(mm):	82 m'm;
Brand Name:	ALMACO;	Supply Ability:	30 Set/Sets per Month;
Function:	Machining Metal;	Machining Capacity:	Heavy Duty;
Tool Post Stations:	4;	Max. Spindle Speed (r.p.m):	2500;
Dimension(LWH):	365519901880mm;	Travel (X Axis)(mm):	600;
Travel (Z Axis)(mm):	2000;	Width of bed (mm):	750;

Recommend Products

Products Description

CNC Lathe machine

The CNC system is optional with FANUC0-TC, 0-TDII or others as required. The hydraulic parts, lubrication unit and chuck are all famous domestic or foreign products as well.

A high precision through-hole spindle driven by powerful AC main motor feature the stability and low noise during operation.

The multi-station turret indexed fast and nonstop bi-directionally with a high repeatability.

The strengthed casting base and exclusive slant bed provide excellent rigidity and dampening, coupled with convenient chip removal.

Key parts like bearing on the ball screw and main spindle are all famous foreign products, ensuring the higher machining accuracy and longer part life.

Specification

ITEM			UNIT	LFNC7516	LFNC7520	LFNC7525	LFNC7530
Capacity	Swing diameter over bed	mm	Φ400	Φ550	Φ550	Φ670
		Max. turning diameter	mm	Φ285	Φ450	Φ450	Φ500
		Max. turning length	mm	400	530	1000/1500	800/1500
		Max. bar diameter	mm	Φ42	Φ73	Φ73	Φ90
Spindle	Type of spindle nose		A2-5	A2-8	A2-8	A2-8
		Spindle bore diameter	mm	Φ57	Φ87	Φ87	Φ105
		Chuck diameter	mm	Φ165	Φ254	Φ254	Φ305
		Spindle speed	rpm	55-5500	30-3000	30-3000	25-2500
		Spindle motor power (Continuous/30min)	Kw	11/15	15/18.5 (*18.5/22)	15/18.5 (*18.5/22)	22/30
Tailstock	Quill diameter	mm	Φ70	Φ9	Φ90	Φ110
		Quill travel	mm	80	100	100	150
		Taper of center (Standard/live spindle)	MT	4/2	5/4	5/4	6/5
Feed	Travel X/Z	mm	165/410	250/1010	250/1010	295/1550
		Rapid traverse rate X/Z	m/min	12/16	16/20 (*12/15)	16/20 (*12/15)	12/16
		Feed motor torque X/Z	N.m	6/12	12/22	12/22	12/22
Turret	Number of turret		12/8	12/8	12/8	8
Turret		Tool O.D. size (turning/boring)	mm	20 x 20/Φ32	25 x 25/Φ40	25 x 25/Φ40	32 x 32/Φ50
Other	Slant degree of bed		45	45	45	60
		Power supply	KVA	35	35	50	60
		Dimension (L x W x h)	mm	2535 x 1672 x 1662	3255 x 1805 x 1850	3655 x 1990 x 1880	4822 x 2244 x 2178
		Weight	kg	3000	4500	5000	8300
Old model					CK7516	CK7520	CK7525	CK7530

Company Profile

Company history

2016:Machine center agent of SMTCL

2012:Established Egypt office and Toronto branch

2010:Established power press factory

2008:Cooperating with Semyx USA,CNC Waterjet OEM

2003:Established Press Brake ,Shearing machine,Rolling machine factory

Every year, we are present in many offline exhibitions. We are professional in import and export of industrial machinery.

Our service

We have established overseas service outlets in Canada, Egypt, and Algeria

TOPTECH SMAC MACHINERY LIMITED
Address:Office and showroom, unit 5, 5510 Ambler Dr Mississauga, ON, L4W2V1, CANADA
Office: 905 238 8912
Contact: Mrs Merry NA

COMPANY REPRESENTATIVE (EGYPT)
Address: Ibn Khaldon St. -Villa No.16-6th District-Obour City-Cairo-Egypt
Tel & Fax: +20244823499
Cell phone: +201223960211
Contact: Ahmed Refaat

SJR MACHINERY LIMITED
Adress: cité 128 logements Bater numéro 71 Sidi el DJILLALI sidi bel abbes 22000 att to Mr mezouar Mohammed mobile number 0542 695
457 and 0770 551 807
Tel: 0542 695 457 ,0770 551 807

Product packaging

We choose the best logistics service to ensure the safe arrival of products in your country.

FAQ

Q.What are your normal lead times? A.Our company typical lead times range from 3-4weeks after receipt of order.

Q.What are the terms of payments you offer? A.We accept payment of T/T, L/C, and Western Union, cash, O/A etc.

Q.What kind of package do you offer? A.Normally in plywood case, to make sure all goods in good condition.

Q.What is the MOQ for your production? A.The MOQ depends on your requirements for color, logo and so on. For some normal items, we have in stock, the MOQ is 1 set.

Q.Do you have CE certification A.Yes, we have CE certification, machine quality is one year guaranteed.

Q.How to control the quality of the products? A.We have always placed great emphasis on the quality level is maintained. Moreover, the principle we always maintain is "to provide customers better quality, better price, and better service". Table Panel Mechanical Horizontal Band Saw for Metal
