2000HP diesel locomotive for railway;high power locomotive ;used railway locomotive

Supplier: Qingdao Ruilan Trading Co., Ltd.
Region: Shandong, China
Contact: Ms linda wang
Price: $10000.00 /set
Min. Order: 1 set

Click here to contact

Product details

Tolerance:	+/-0.5m;	Packaging Detail:	As per your demand;
Speed (km/h):	120KM/H;	Delivery Detail:	20 days;
Brand Name:	CKD4C;	Standard:	AAR and so on;
Place of Origin:	China;	Certification:	ISO9001:2008;
Fuel Type:	Diesel;	Dimensions (L x W x H) (mm):	AS your drawing;
Model Number:	CKD4C;	Port:	Qingdao,shanghai and other china main port;
Payment Terms:	L/C,D/A,D/P,T/T,Western Union,MoneyGram;	Horsepower:	as your drawing;
Supply Ability:	10000 Set/Sets per Year;

CKD4C high power diesel locomotive is used for the railway transportation business in the middle and western area .

CKD4C diesel locomotive is high power AC-DC diesel locomotive for trunk line heavy-loaded freight locomotive. This locomotive is equipped with 16V28OZJA diesel engine, JF204D synchronous main generator and ZD109E traction motor, adopting monocoque fuel tank and running gear of 3-axle bogie with weight of 25 ton.

Appl ication :	Mainly for freight transportation in main line
Operation conditions:	Ambient temperature : 18°C ~45°C
	Altitude: 1200m
	Relative humidity.100%
Gauge	1435mm
Clearance	UIC 506-GC
Transmission Mode	AC —DC electric transmission
Axle arrangement	Co —Co
Wheel Diameter	1050mm
Axle Load	25 + 0.75 t
Calculated Gross Weight	150±4.5 t
Max. Service Power	3100kW UIC Condition

Max. Service Power of Engine	3680kW Under the UIC condition, the amendment mode of engine power adopts CIMAC formulation, which rely on concrete figure of circumstance temperature and latitude to carry out amendment.
Speed of Locomotive	Calculated wheel diameter is half abrasion condition, namely 1013 mm.
Max. Test Speed	1 10km/h
Max. Service Speed	100km/h
Continuous Speed	28.2km/h
Traction Effort at wheel rim	Calculated wheel diameter is half abrasion condition, namely 1013 mm.
Max. Starting Effort
Continuous Effort	369kN
Min. Negotiation Curve Radius	145m
Wheelbase	1800mm
Bogie Wheelbase	3600mm
Total Wheelbase of Locomotive	15900mm
Locomotive Dimensions
Length Between Coupler Pulling Faces	22000mm
Width	2950mm
Height	4650mm
Capacity of fuel tank	9000L
