2.5 ton mining battery locomotive for undergroud tunnel

Product details

2.5 ton mining battery locomotive for undergroud tunnel

Factors causing insufficient traction in mining locomotives

Insufficient traction in mining locomotives can be attributed to various factors. Understanding these factors is crucial for identifying and addressing the underlying issues to ensure optimal performance. Here are some of the key factors:

1. Deterioration of the speed regulator: When the speed regulator deteriorates, it can lead to a lower voltage output, resulting in reduced traction force.

2. Faulty current transformers: The performance of current transformers plays a critical role in accurately measuring and controlling the current flow. A faulty current transformer can affect the traction capabilities of the locomotive.

3. Severe degradation of the filtering capacitors: The filtering capacitors are responsible for maintaining stable power supply and reducing electrical noise. When these capacitors severely deteriorate, it can impact the traction force of the locomotive.

4. Malfunctioning control drive box (ND300): The control drive box is a crucial component in managing the locomotive's traction and speed control. Any malfunction or defect in this component can result in reduced traction performance.

5. Defective IGBT modules: The Insulated Gate Bipolar Transistor (IGBT) modules are responsible for controlling the power flow in the locomotive's traction system. Defective IGBT modules can lead to insufficient traction force.

6. Faulty electric motor: The electric motor's performance directly affects the locomotive's traction capabilities. A faulty motor can result in reduced power output and traction force.

7. Poor welding of track return lines: Inadequate welding of the track return lines can cause disruptions in the electrical circuit, leading to a decrease in traction force.

Identifying and rectifying these factors requires a systematic approach, including regular inspections, maintenance, and timely replacements of faulty components. By addressing these issues promptly, mining locomotives can maintain optimal traction performance, ensuring efficient and safe operations.

It is essential to consult with experts and follow manufacturer guidelines for troubleshooting and resolving traction-related issues in mining locomotives. Proper maintenance and adherence to best practices will contribute to the overall productivity and longevity of the locomotive fleet.

2.5 ton Battery locomotiveAdhesive / total weight (t)2.5 ton
Track gauge (mm)600.762.900
Traction (KN)2.55
Max. Traction (KN)6.13
Speed(km/h)4.54
Battery Voltage (V)48V
Battery Capacity (Ah)330
Power (KW)3.5 KWx1
Dimensions Length(mm)2330
Width(mm)914,1076or 1212
Height(mm)1550
Wheelbase (mm)650
Wheel diameter (mm)460
Min Curve radius (m)5
ControllerResistencia or IGBT
Braking methodMechanical
Detailed Photos

Advantages of our product

1.Using high-quality steel plates, special rust removal process make sure it more anti-corrosion and suitable for harsh mining environment.
2. Producing motors ourselves, using high lever insulation material and pure copper, ensure the powerful traction force, and suitable for harsh mining environment.
3.Gear anastomosis surface to reach more than 80%, which is far more exceeding the standard.
4.Professionally designed and adjusted frame ensure safe driving and avoids falling off rails.
5.A variety of braking methods can be choose, air brake, hydraulic brake, electric brake, mechanical brake to ensure the safety drive.
6. 40 years richful experience with the ability to design and make customized product according to your requirements.
7. Proving factory online-visiting2.5-Ton Mining Accumulator Locomotive Powered by Lithium Battery

Factory Test

Mining Locomotive test
1.Before Running the locomotive,carry out gear debugging, lighting, gear, and brake adjustment etc.To ensure the normal operation of the locomotive.
2.Carry out a tensile test before leaving the factory to ensure the load performance of the locomotive meets the standard. Our design standards generally exceed the national standard by 10%-20%.
3.Carry out different type running test before leaving the factory to ensure the performance and normal operation of the whole locomotive. It can adapt to various harsh conditions under simulated working conditions.

Motor test
The motor has to go through many inspection procedures before leaving the factory, and each motor has to be carried out with load running experiments.
Explosion-proof motors are carried out with water pressure test.
All the test of motor is to ensure that can adapt to harsh working conditions.2.5-Ton Mining Accumulator Locomotive Powered by Lithium Battery

Cases

1. A good feedback of our lithium battery locomotive from a client of Latin America
2. In order to solve the exist problems of lead-acid batteries. More than 30 lead-acid battery electric locomotives in this large mining were changed into lithium battery electric locomotives, which improved the work enthusiasm and production efficiency of employees, reduced costs,and more environment-friendly.
3. The mining rock drill car designed by Sunward Co., has a small size and simple structure, so the space for placing the lithium battery on the body is very limited.
According to the limitation size, our company design a lithium power supply power plan, which
perfectly solves the problem of lithium power supply space.
In order to adapt to the special industrial and mining environment and improve transportation efficiency, a batch of 2.5-ton lithium battery electric locomotives are designed to Myanmar Clients.2.5-Ton Mining Accumulator Locomotive Powered by Lithium Battery

FAQ
What's your product advantages?

We have more 40 years experience in this field so that we could design or produce the locomotive as your requirement. We could also provide online service to teach you how to operate and maintain the locomotive.
The most important thing that we produce the main part of the locomotive- The traction motors. we could guarante the power of the locomotive.

1.Pre-sales Service:
The wide product range enables us to provide our customers with individual machines or complete processing plants. Based on our customer's request and budget, our experts make efficient and reliable solutions, and we produce strictly follow customers' order. What's more, every customer has the chance to visit the working machine in the site before placing the order.

2.After-sales Service:
Experienced technicians guidance is available on the phone, and on the internet. One or more engineers will be dispatched to the quarry site to help install the customer's plants.Necessary training about machine daily maintenance to local workers is provided also.

3.Methods of Payment:
 T/T (Telegraphic Transfer) or Western Union or L/C at sight
Handling time for an order:
Within 10 days supplied from stock

4.Shipping method:
Sample order: we suggest Courier express like DHL/UPS/TNT/FEDEX or by air
Bulk order: we suggest by air or by sea.
