15KW EV Parts with Motor, Controller and Battery etc

Supplier: Guangdong Shinegle New Energy Technologies Co., Ltd.
Region: Guangdong, China
Contact: Ms SHINEGLE CN
Price: $599.00 /set
Min. Order: 1 set

Click here to contact

Product details

Supply Ability:	10000 Set/Sets per Month;	Motor Type:	AC Motor;
Place of Origin:	Guangdong China;	Peak Torque:	150N.m;
Delivery Detail:	15 days;	Payment Terms:	L/C,D/A,D/P,T/T,Western Union,MoneyGram;
Rated Speed:	3000r/min;	Weight:	55kg;
Rated Power:	15kw;	Model Number:	15kw;
Brand Name:	SHINEGLE;	Color:	Silver;
Rated Torque:	65N.m;	Protection Grade:	IP67;
Rated Voltage:	108V;	Name:	EV Parts;
Max. Speed:	7500r/min;	Packaging Detail:	Seaworthy Packing;
Port:	SHENZHEN/GUANGZHOU/FOSHAN;

Product Description

Product Application

SHINEGLE motor,controller,gearbox,battery,charger,etc.are widely used in electric conversion vehicles

SPECIFICATIONS FOR 25 TON CRAWLER EXCAVATOR
Motor	Rate Power:7.5/10/15KW	Duty:S1	Max speed:7500 rpm
	Rate voltage:72/96/108V	Net weight:35~50kg	Speed sensor:64 Pulse
		Rated speed:3000~4500rpm
Controller	Rated voltage:72/96/108V	Rated output current:100/120	Max output current:500A
	Efficiency:98%	Protection grade:IP65	Packing:wooden box
	Net weight:5~10kg	Ambient temperature:-40 ~ 50℃	HS:8714990000
Gearbox	Speed capacity:9000 rpm	Ratio:6:1/8:1/10:1/12:1	Packing:Wooden box
	Torque capacity:180N.m	Center distance:50~106mm	HS:7326909000
	Noise:≤65dB	Est. net weight:15~30kg

Main Features

1) High torque and fast speed

2) Hands-on instruction, installation and use

3) Provide customers the fastest system solutions

4) Work with clients to calculate and test

5) Long time system testing, product maturity

Certifications

Detailed Images

Machine Parts

Name: Motor

Brand: SHINEGLE

Original: China

Maintenance-free motor. It is the most promising motor for electric vehicles. Compared with DC motor, AC motor has more advantages, like larger torque.

Main Features

Name: Controller
Brand: SHINEGLE
Original: China
Vector control is one of the best ways to control motor. We have tested this system for more than 10 years, and the current stability is very high.

Machine Parts

Name: Gearbox
Brand: SHINEGLE
Original: China
Low noise and high transmission efficiency are the two main advantages of the gear box

Main Features

Name: Battery and Charger
Brand: SHINEGLE
Original:China
At present, China's lithium-ion battery cell production technology is in the world's leading position. We can provide 100000 km protection for our customers.

Our Service

Pre-Sales Service

* Customer sends inquiry

* Tailor the right system

* Sample testing support.

After-Sales Service

* Timely technical communication

* Result feedback and improvement

Packing & Delivery

Packing
Size	1280 (L) * 456 (W) * 789 (D)
Weight	1.2 T
Packing Details	Normal packing is wooden box(Size: LWH). If to european countries,the wooden box will be fumigated. If container is too high,we will use PE film for packing or pack it according to customers special request.

Packaging
Size	123 (L) * 456 (W) * 789 (D)
Weight	100kg
Packing Details	Normal packing is wooden box(Size: LWH). Sometimes we choose cartons when by air
