High Speed HDPE Ldpe Plastic Film Garbage Bag Dual Die Blown Film Extrusion Machine

Supplier: Ruian Zhonglong Plastic Machinery Co., Ltd.
Region: Zhejiang, China
Contact: Mr James Lee
Price: $5900.00 /set
Min. Order: 1 set

Click here to contact

Product details

Voltage:	380V (220V, 440v optional)	Package preview:
Mechanical test report:	if	automatic:	Yes
Plastic processing:	Polyethylene, High Density Polyethylene, Low Density Polyethylene, Polyethylene	Video shipment inspection:	if
Marketing Type:	New Products 2021	Core component warranty:	1 year
Showroom location:	not any	brand:	Zhonglong
port:	Ningbo Port	model:	SJ series
Warranty:	one year	After-sales service provided:	Engineers available to service machinery overseas
Dimensions (LWH):	4600x1800x3600mm	Layers:	single layer
Main selling points:	Motor, gearbox, die head	Core components:	Motor, screw, die head
Supply capacity:	1000 sets per year	product name:	PE film blowing machine
application:	Movie	Blow molding type:	extrusion blow molding
Packaging Details:	Wooden case or soft package depends on your request and delivery method	Weight (kg):	2500
Output (kg/h):	35 - 50	Origin:	Zhejiang, China
Applicable industries:	Food and Beverage Factory, Farm	Health status:	new
payment terms:	L/C, Western Union, T/T, MoneyGram

Top High Speed ABA 3 2 Layers Mini Stretch HDPE LDPE Film Extrusion Machine PE Plastic Blown Film Machine

product information

usage
Blowing PE (HDPE, LDPE, LLDPE), plastic film blowing machine for film; ETC.
Which films are widely used in the packaging of liquids, industrial products, clothing and textiles; used to make plastic bags, such as T-shirt bags, flat bags, garbage bags, etc.
feature
1. The frequency converter controls the main motor and traction motor.
2. Material of screw and barrel: 38CrMoAl-A after nitriding treatment.
3. Gear box: hard tooth surface gear, cast alloy piston, high precision grinding, long life.
4. Mold material: alloy steel, hard chrome plated, mirror channel steel.
5. Die head double digital display temperature controller.
6. The whole machine has passed CE certification, our factory has passed ISO certification, and the quality is guaranteed.
Elective
1. Rotary die head
2. Double station winder
3. Lifting traction
4. PLC automatic film changing winding machine
5. Automatic feeding
6. Corona treatment
7. Filter replacement system

scope
Model	SJ-50	SJ-55	SJ-60	SJ-65	SJ-75	SJ-100
maximum. Film folding width	600mm	800mm	1000mm	1200mm	1500mm	2000mm
main output	35 kg	35-50kg	55-65 kg	55-70 kg	70-80 kg	200-220kg
main motor power	7.5-11kw	11-15kw	15-18.5kw	18.5-22kw	30-37kw	55 kW
Screw diameter	50mm	55mm	60mm	65mm	75mm	100mm
Screw aspect ratio	28:1	28:1	28:1	28:1	28:1	28:1
Screw speed	10-100 rpm	10-100 rpm	10-100 rpm	10-100 rpm	10-100 rpm	10-100 rpm
membrane thickness	0.01-0.10mm	0.01-0.10mm	0.01-0.10mm	0.01-0.10mm	0.01-0.10mm	0.01-0.10mm
Die	60-120mm	100-170mm	100-170mm	120-220mm	150-300mm	500mm
machine weight	2000 kg	2500 kg	3600 kg	4200 kg	6000 kg	7500 kg
Dimensions [LWH]	4.51.83.5m	5.52.03.8m	6.02.24.2m	6.02.44.3m	7.02.75.8m	8.03.28.2m
