Self-starting generator fire-fighting type dual power supply automatic switching isolation ATS

Supplier: Yueqing Lanpu Electrical Co., Ltd.
Region: Zhejiang, China
Contact: Mr Alan LAU
Price: $24.00 /piece
Min. Order: 1 piece

Click here to contact

Product details

maximum. Voltage:	450V	Is it smart:	No
payment terms:	T/T, MoneyGram	Supply capacity:	10 per day
pole:	3P 4P	Certification:	CE certification
Rated current:	up to 3200A	Origin:	Zhejiang, China
Mechanical life:	20000 times/time	Material:	silver contact
connect:	Terminal type, stable working condition	maximum. current:	3200A
Certificate:	CE certification	brand:	LNP
port:	Ningbo/Shanghai	Life:	electric operation
product name:	Dual power automatic transfer switch ATS	Operation:	manual and automatic, or manual
model:	HQ5	Rated frequency:	50/60 Hz
Packaging Details:	fragments

application:
The HQ5 ATS is used in generator systems, converting two power sources. Widely used in the following fields
Important power supply places for transportation, power distribution and power supply systems and automation systems.
It is used in places where power failure is not allowed, such as firefighting, hospitals, banks, and buildings.

1. Basic specifications:

Conventional thermal current lth	20	40	63	80	100	125	160	250	400	630	800	1000	1250	1600	2000	2500	3200
Rated insulation voltage Ui	750V								1000V
Rated impulse withstand voltage Uimp	8KV								12KV
Switch copper wire rated voltage	AC 440V
Rated operating current le AC-33A	20	40	63	80	100	125	160	250	400	630	800	1000	1250	1600	2000	2500	3200
Rated connection capacity	10 music
Rated breaking capacity	10 music
Rated condition short-circuit current	100KA								70KA			100KA		120KA		80KA
Rated short-time withstand current IS	7KA			9KA		13KA			26KA			50KA		55KA
Transfer time I-II or II-I	0.45s								0.6 seconds			1.2 seconds				2.4s
Switching Motor Control Voltage	DC24V AC220V AC280V

Performance:

1. Double compound contacts, basically horizontal and vertical frames, to achieve "zero" arc (without arc extinguishing chamber);

2. Reliable mechanical interlock and electrical interlock, the executive linkage parts adopt independent overload isolating switch,
It makes more reliable and safe.

3. "Return to zero" technology, which can be forced to "zero" in an emergency (cut off two power supplies at the same time). Meet fire linkage requirements.

4. The switching of the operating overload isolation switch is driven by a single motor, the switching is stable and reliable, and there is no noise.
small impact

5. The driving motor of the manipulator only uses the disconnect switch to switch the instantaneous current through when the overload is performed, and the energy is outstanding.

6. Implement overload isolating switch with mechanical interlock device. Ensure normal operation of common and backup power supplies
Reliable and undisturbed.

7. Obvious on-off position indication, padlock function, etc. to safely realize the isolation of power supply and overload

8. High safety, high automation, high reliability, service life greater than 8000 times
