yeq2 single-phase three-phase automatic transfer switch ats 63A 220V transfer switch 2p 3P4P

Supplier: Jiangxi Shuanghong Technology Electric Co., Ltd.
Region: Jiangxi, China
Contact: Mr Franz Wang
Price: $10.00 /unit
Min. Order: 1 unit

Click here to contact

Product details

Certification:	CE, CB, ISO9001, CE ISO ccc	Packaging Details:	carton
maximum. current:	1250A	frequency:	50/60 Hz
Supply capacity:	10000000 pieces per month	Whether smart:	Yes
feature:	High security, high automation, high reliability,	Mechanical life:	10000
Function:	automatic transfer switch	model:	YEQ2 automatic transfer switch ats
pole:	2P, 3P, 4P	Origin:	Jiangxi, China
brand:	Processing	port:	FOB NB/SH
maximum. Voltage:	220V/380V/400V	Rated current:	6-1250A
payment terms:	L/C, T/T, Western Union	Control voltage:	220V
Rated voltage:	380V	Transfer time:	1.5-3S

Automatic Transfer Switch ATS Automatic Transfer Switch ATS Automatic Transfer Switch ATS Automatic Transfer Switch ATS Automatic Transfer Switch ATS Automatic Transfer Switch ATS

Product Description

General introduction
YEQ2 series automatic transfer switch is the best-developed generation product of our company.
Mainly used for monitoring power circuits. When the main power fails, it will switch to the backup power
Automatic power supply, thus completing the transformation of the power system. Currently, especially
It is suitable for important power places where faults are not allowed to meet the needs of users
Automatic switching has self-input and self-recovery, self-input without self-recovery, practical to practical,
The public generator has multiple functions, this product is suitable for 220V, AC 50Hz, the rated current is
10A to 1250A (CB level) automatic switching products.
Structure and Features
YEQ2 series intelligent double power automatic switch consists of two units of 3 poles and 4 poles.
Molded case circuit breaker and (auxiliary contact, alarm contact), mechanical interlocking transmission, intelligent controller
and other components. There are two kinds of institutions, integral and split. Integrated controller
Equipped with a base and an actuator; the split type is an intelligent controller installed on the panel
The user takes the base through the actuator and installs it in the controller cabinet with a cable of about 2m.
There is a reliable mechanical interlock between the two circuit breakers and the electrical interlock device. eliminate
Both devices are completely turned off at the same time.
The use of single-chip intelligent controller to control the core hardware is simple, powerful, easy to expand, and high in reliability.
With short circuit, overload protection function, overvoltage, undervoltage, phase loss automatic protection
Transmission function and intelligent alarm function.
The external parameters of automatic switching can be set freely.
Operation of intelligent motor protection
The control circuit is equipped with a fire-fighting device, and the fire-fighting control center sends the control signal to the intelligent controller. two
Set the circuit breaker to enter the breaking state.
There is a computer network interface to realize remote control and four remote telemetry functions
