Industrial battery 100kWh high voltage commercial battery cabinet all-in-one hybrid inverter solar battery energy storage system
- 49450.00 1 - 10 pieces
- 44275.00 11 - 50 pieces
- 40250.00 51 - 200 pieces
- 31625.00 >=201 pieces
Registered Supplier
Direct Contact
Inquiry via Message
Product Details
| port: | Shenzhen | Chemical type: | life treasure 4 |
| range of working temperature: | -20℃~60℃ | voltage range: | 400v~750v |
| Supply capacity: | 1000 pieces per day | cooling method: | HVAC |
| Warranty: | 10 years | brand: | Liyuan |
| payment terms: | L/C, Western Union, D/P, D/A, T/T | model: | 115kwh/50kw battery system |
| IP protection level: | IP54 | Origin: | Guangdong Huizhou |
| Battery Type: | Lithium Ion Battery | Communication Interface: | Ethernet RS485 CAN |
| AC rated power: | 50KW | Protocol: | Protocol/IP |
| ESS container size (W*D*H): | 2100*2000*1000mm |
Product Description
detailed drawing
Product parameters
Warranty | 10 years |
brand | Liyuan |
battery capacity | 115 kWh |
battery voltage range | 400~750V |
AC rated power | 50 kW |
Dimensions (L*W*H) | 2100*2000*1000mm |
IP rating | IP54 |
range of working temperature | -20℃~60℃ |
AC output voltage | 400VAC |
Alternating current | 65A |
Communication Interface | RS485, CAN, Ethernet |
Protocol | Protocol/IP |
AC frequency | 50/60 Hz |
cool down | Air Cooling and Heat Exchangers |
cycle life | >5000 cycles@25℃ 0.5C/0.5C |
weight | About 1500kg |
oxidizing agent | FM200 or NC1230 |
certified | IEC62619, CE, UL9540A, UL1973, UN38.3, CE LVD, IEC62477, CE EMC, G99, VDE4110 |
delivery time | 3 months |
touch | For more details, please contact us for free. |
