600mm Micro Tunnel Boring Machine Pipe Fixing Machine XDN600 XDN600H-L

Supplier: Maxizm Construction Machinery (Qingdao) Co., Ltd.
Region: Shandong, China
Contact: Ms Bunny Cong
Price: $105000.00 / 1 - 2 units
$88000.00 / >=3 units
Min. Order: 1 unit

Click here to contact

Product details

Dimensions (LWH):	770*3200mm	Core component warranty:	1 year
Warranty:	1 year	Pipe diameter (ID):	600mm
port:	Shanghai Port, Qingdao Port, etc...	Showroom location:	not any
Marketing Type:	normal product	weight:	4100 kg
Pipe diameter (outer diameter):	750mm	Supply capacity:	1000 units per year
Packaging Details:	naked bag	Applicable industries:	Building materials stores, machinery repair shops, construction, energy and mining
payment terms:	L/C, Western Union, D/P, D/A, T/T, MoneyGram	place of origin; place of origin:	Jiangsu, China
brand:	China's first	Motor Power:	37KW
Video shipment inspection:	if	Number of cylinders:	3EA
Mechanical test report:	if	Slurry line diameter:	75mm
Force per cylinder:	217KN	State of health:	new
revolution:	12 rpm	Moment:	34KN.M
Launch shaft size:	2900mm	Core components:	PLC, engine, bearing, gearbox, motor, pressure vessel, gear, pump
Outer Diameter*Length:	770*3200mm

touch

Judy Zhang

sales Manager
Phone/Skype/Whatsapp: +8617852035877
WeChat: +86 18874360427
E-mail: judy@maxizm.com

Meizhi Construction Machinery (Qingdao) Co., Ltd.Meizhi Industrial Co., Ltd.

URL: www.maxizm.com

We have specialized in exporting construction machinery and vehicles for 13 years. Product range: truck cranes, crawler cranes, loaders, excavators, bulldozers, road rollers, motor graders, tractors, forklifts, concrete machinery, etc.

Xuzhou famous brand tunnel boring machine 600mm hard rock pipe jacking machine XDN600 XDN600H-L

Product Description

600mm Hard Rock Pipe Jacking Tunnel Drilling Micro Tunnel Boring Machine XDN600

1. High reliability:
The hydraulic overload protection system is reliable and safe, and has good waterproof performance.
2. Strong geological adaptability:
The speed is steplessly adjustable, and different cutting wheels are designed for different ground conditions, with strong adaptability.
3. High rock breaking efficiency:
The special design of the large eccentric cone crusher improves the working efficiency of the secondary crushing and makes the stones easier to discharge.
4. Good construction operability:
Jacking speed and mud flow are continuously adjustable, making it easier to achieve a balance between jacking speed and mud flow.

Product parameters

describe			unit	parameter value
Diameter	ID	mm	Φ600
Diameter		mm	outer diameter		Φ750
Outer diameter x length			mm	Φ770×3200
rotating system	Motor Power	kilowatt	37
		torque	KNm	34
		revolution	rpm	12
Roll Correction System	force per cylinder	thousand cattle	217
		number of cylinders	EA	3
		steering angle	°	3
Sizing line diameter			mm	Φ75
weight			Kilogram	4100
Lifting system motor power			kilowatt	15
Jacking cylinder	thrust	thousand cattle	1000
		number	EA	2
		stroke	mm	760×2
Launch axis size			mm	Φ2900
Receiving shaft size			mm	Φ1900
Charge pump motor power			kilowatt	5.5
Discharge pump motor power			kilowatt	11
Fuel injection pump motor power			kilowatt	4

detailed drawing
