collaborative robot JAKA Zu12 arm small industrial robot with 12 kg load cobot arm robot
- 8500.00 set
Registered Supplier
Direct Contact
Inquiry via Message
Product Details
| feature: | cooperation | brand: | Jaka |
| Packaging Preview: | Weight (kg): | 12 | |
| User digital I/O: | 16/16 | Mechanical test report: | if |
| Marketing Type: | Hot Products of 2019 | Core Components Warranty: | 1 year |
| Dimensions (L*W*H): | 460x375x365 (mm) | Card: | Jaka |
| Warranty: | 12 months | place of origin; place of origin: | China |
| strength: | 150 watts | Base size: | 129 mm |
| Packaging Details: | Standard export carton | Video external inspection: | if |
| payment terms: | wire transfer | Production capacity: | 200 sets/month |
| Repeatability: | ±0.02mm | application: | Choose a location |
| port: | Hongkong | Model: | Zu 12 |
| communicate: | TCP/IP | Arm span: | 1252 mm |
| Supply capacity: | 100 sets per month | Showroom location: | not any |
| Health status: | new | weight: | 12 kg |
| Voltage: | 100~240VAC | Axle number: | 6 degrees of freedom |
| Applicable industries: | Manufacturing Plants, Food and Beverage Plants | Core components: | PLC, gearbox, motor |
| Payload: | 3 kg |
Product Description
JAKA Zu12 6 axis 12kg product parameters | ||
Payload | 12kg | |
Weight (W cable) | 41 kg | |
working radius | 1327 mm | |
Repeatability | ±0.02mm | |
axis | 6 | |
programming | Graphical programming, free drive | |
teach pendant | MT (PAD/mobile phone) APP | |
Collaborative work | Comply with GB 11291.1-2011 | |
Certificate | China Resources Tong 15066 | |
rated power | 150 watts |
temperature range | 0-50℃ |
Intellectual Property Specifications | Intellectual Property 54 |
Install | Installation at any angle |
Tool I/O | Digital Input 2/Digital Output 2/Analog Input 1 |
Tool I/O Power | 24V |
Base diameter | 129mm |
Material | Aluminum, PC |
Tool I/O Size | M8 |
cable length | 6m |
Package dimensions | 460×375×365(mm)(L×W×H) |
parameter | The scope of work | |
Intellectual Property Specifications | IP44 | |
Tool I/O | 16 digital inputs, 16 digital outputs, 2 analog inputs or outputs | |
Input/Output Power | 24V | |
communicate | TCP/IP, Modbus TCP, Modbus RTU | |
strength | 100-240VAC, 50-60Hz | |
Cabinet size | 410×307×235(mm) (W×H×D) | |
Package dimensions | 600×325×400(mm)(L×W×H) | |
Weight (W cable) | 16kg | |
Material | Stainless steel | |
robot | The scope of work | Maximum speed |
Connector 1 | ±360° | 180°/sec |
Connector 2 | -85°, +265° | 180°/sec |
Connector 3 | ±175° | 180°/sec |
joint 4 | -85°, +265° | 220°/sec |
joint 5 | ±360° | 220°/sec |
joint 6 | ±360° | 220°/sec |
Maximum speed | / | 1.5m/s |
Product packaging
