nivo LNU45 4.5M Asphalt Asphalt Asphalt Mini Paver Concrete Asphalt 2m Asphalt Asphalt Asphalt With Crawler Base
- 3658.00 unit
Registered Supplier
Direct Contact
Inquiry via Message
Product Details
| Mechanical test report: | if | Packaging Details: | nude |
| Warranty: | 1 year | payment terms: | L/C,Western Union,T/T,MoneyGram |
| Dimensions (L*W*H): | 5820*4534*2995mm | engine model: | QSB3.9-C80-31 |
| Engine Brand: | Cummins | Maximum gradeability: | 20% |
| Marketing Type: | Hot Products of 2019 | Unique Selling Points: | High operating efficiency |
| type: | 4 cylinder water cooling | brand: | Niwo |
| Production capacity: | 220 tons/hour | length: | 5820mm |
| Smoothness: | 3mm/3m | Health status: | new |
| Driving speed: | 1.55~4.62 km/h | place of origin; place of origin: | Jiangsu, China |
| Minimum Paving Thickness: | 10mm | Applicable industries: | Hotels, Clothing Stores, Building Materials Stores, Mechanical Repair Stores, Manufacturing Plants, Food and Beverage Plants, Farms, Restaurants, Home Use, Retail, Food Stores, Printing Stores, Construction Works, Energy and Mining, Food and Beverage Stores, Advertising Agencies |
| Packaging Preview: | port: | Shanghai | |
| Supply capacity: | 20 units per day | Core Components Warranty: | 1 year |
| Video external inspection: | if | maximum. Paving thickness: | 250mm |
| strength: | 60kW | Showroom location: | not any |
| Paving speed: | 2.03~6.07 m/min | Core components: | PLC, engine, bearing, gearbox, motor, pressure vessel, gear, pump |
| width: | 4534mm | Diesel Fuel Tank Capacity: | 143L |
| weight: | 10 kg |
Product Description
Specifications 2.5-12.5m paving width optional wheel / crawler, concrete paver...
It is suitable for laying highways, urban roads, squares, squares, etc. It uses an advanced dual-group hydraulic stretch screed and
Automatic level induction device, high paving density and flatness. The wearing parts adopt international advanced
Anti-friction material to improve machine reliability.
Automatic level induction device, high paving density and flatness. The wearing parts adopt international advanced
Anti-friction material to improve machine reliability.
Specification | ||
Paving width(mm) | 2500-4500 | |
Paving thickness (mm) | 10-250 | |
Driving speed (km/h) | 1.55～4.62km/h | |
Paving speed (m/min) | 2.03～6.07 m/min | |
smoothness | 3mm/3m | |
maximum. Theoretical output (t/h) | 250 | |
Hopper capacity (tons) | 10 | |
Maximum gradeability | 20% | |
Hopper capacity | 10T | |
engine | Cummins QSB3.9-C80-31 | |
strength | 60Kw/2200r/min | |
detailed picture
wheel types available
different spare parts
Concrete paver can be optional
