Brand new 14m bucket truck aerial work platform truck

DONGFENG 12M AERIAL PLATFORM TRUCK

Vehicle Parameters

General

YZR5040JGK12QVehicle Model

YZR5040JGK12E

Vehicle Brand

XDR

Chassis Brand

Isuzu

Overall Dimension(mm)

5998×2000×2960

GVW/Curb Weight(kg)

4495/4170

Chassis Parameters

Cab

Cab Seat

2

Air Conditioner

Optional

Engine

Fuel Type

diesel

Engine Model

4KH1CN5LS

Engine Brand

isuzu

Power

98hp

Displacement(cc)

2999

Emmission Standard

Euro5

Chassis

Drive Type

4*2

Transmission

5 speed, Manual

Wheelbase(mm)

3360

Tyre Specification

7.00R16

Tyre No.(pcs)

6+1

Max Speed(km/h)

105

Paint

Yellow

Aerial platform structure parameters

working height(m)

12

Maximum working radius(m)

6.2

Arm Material

carbon steel Q345

Arm Thickness

Working height at Max.working radius(m)

8.1

Working radius at Max.working height(m)

3

Outrigger distance(mm)

3040*2890

Platform average rise speed(m/s)

≤0.4

Platform average fall speed(m/s)

≤0.4

Rotation speed (1r/min)

1

Arm structure type

Three section

Outrigger stretch time (s)

40

Rotation

360°continuous rotary

Outrigger

H type,independently

Remarks

1. truck chassis brand is selectable 2.he outrigger operation box is equipped with a lighting device to facilitate work at night
and configure the vehicle's bidirectional level to ensure the vehicle's level and ensure safety.3.The boom rotation is designed as
a one-piece swivel to avoid assembly gaps during reassembly in production, and increases the space of the platform.4.Front and
rear H-shaped legs, good stability, can be operated simultaneously or individually, standard washing boxes for all models 5.Upper
arm limit device, when the upper arm exceeds the safety angle, the boom will be in a self-locking state to ensure the safety of
the operator 6.Up and down steps are equipped on the side(aluminum alloy platform optional )7.The thickened cylinder seat and the
boom cylinder block are all specially thickened to ensure the stability of the boom 8.Sectional coating to ensure the paint
quality of the vehicle 9.All cutting parts are CNC laser cutting
