Crystallization Jacketed Glass Reactor 10L to 200L

Supplier: Labfirst Scientific Instruments (shanghai) Co., Ltd.
Region: Shanghai, China
Contact: Mr Alex Huang
Price: $4990.00 / 1 - 2 sets
$3990.00 / >=3 sets
Min. Order: 1 set

Click here to contact

Product details

Rotating speed(rpm):	0-680;	Vacuum Degree:	-0.098Mpa;
Brand Name:	lab1st;	Machinery Test Report:	Provided;
Neck no. on lid:	6pcs;	Single gross weight:	130.0 KG;
Voltage:	220v/110v,220V/50HZ;	Glass Material:	High Borosilicate Glass 3.3;
Video outgoing-inspection:	Provided;	Type:	Tank Reactor;
Power:	120W~370W;	Core Components:	Motor;
Applicable Industries:	REACTION;	Capacity:	10L~100L;
Marketing Type:	New Product 2020;	Warranty:	1 Year;
Dimension(LWH):	*;	Selling Units:	Single item;
After Warranty Service:	Spare parts;	Stirring power:	120w~370w;
Packaging Detail:	Jacketed Glass Reactor will use qualified wooden package and sufficient inner protection for fixed bed reactor;	Place of Origin:	Shanghai China;
Weight:	*;	After-sales Service Provided:	FREE PARTS;
Local Service Location:	Canada,United States;	Single package size:	2000X1000X1000 cm;
Key Selling Points:	Long Service Life;	Working temperature:	-60 to 200°C;
Volume:	10L~200L;	Condition:	New;
Automatic Grade:	Automatic;	Showroom Location:	United States;
Certification:	CE ISO;	Warranty of core components:	1 Year;
Sealing Material:	PTFE;

Products Description

Lab1st JGR-F Series Decarboxylation Reactor

The crystallization process is a commonly used glass reactor for biochemical refinement, which combines the functions of the reactor and the filter. Lab1st crystallization reactor can make crystallization concentration, distillation, reflux, separation and purification which is an ideal instrument for cbd oil processing.

Product Details

Product Paramenters

Model	JGR-20F	JGR-30F	JGR-50F	JGR-100F	JGR-200F
Reaction Capacity (L)	2~20	5~30	5~50	10~100	30~200
Jacketed Volume (L)	6	10	16	30	40
Total (pcs)	5+1	5+1	5+1	5+1	5+1
Stirrer Port	50#	50#	50#	60#	60#
Air charging valve	34#	34#	34#	34#	34#
Solid feeding Port	80# Flange
Thermometer Tube	DN25 Flange
Reflux Separator	50#	50#	50#	50#	50#
Reflux Separator		Ball Mill Mouth
Condenser Port	34#, spiral condenser
Constant Pressure Drop Funnel	40#,1000ml	40#,2000ml	40#,2000ml	40#,2000ml	10L
Filter Flate	PTFE 1mm
Filter Parts	PTFE Sand core filter plate （25μm)
Filter Parts		T-polyester/T-polyester filter cloth （2μm）
Discharge port	OD:32mm, ID:22mm
PTFE Stirrer	Four-blade Type
