3 Ton Cheap Price Hand Operated Chain Hoist Ratchet Puller Lever Block

Supplier: Foshan Lomba Lifting Machinery Co., Ltd.
Region: Guangdong, China
Contact: Mr Joe Cheng
Price: $95.00 / 1 - 9 pieces
$42.00 / 10 - 99 pieces
$29.00 / >=100 pieces
Min. Order: 1 piece

Click here to contact

Product details

Package Preview:	;	Lifting height:	1.5M-3M;
Place of Origin:	Hebei China;	Payment Terms:	L/C,T/T,MoneyGram;
Port:	Tianjin or Guangzhou;	Certificate:	CE;
Load chain:	G80;	Model Number:	VL;
Supply Ability:	10000 Piece/Pieces per Month;	Capacity:	0.8-6 ton;
Packaging Detail:	Standard export packing;	Chain painting:	Galvanzied or Black coating;
Name:	lever hoist;	Brand:	OEM;
Color:	Black, Yellow, Orange, White, Blue;

Product Description

VL Type 0.75Ton to 6Ton Lever Hoists G80 Chain Manual Hoist block

Technical Features

1. One touch operation free chain adjustment

2. Grade 80 alloy load chain ISO and GES standard

3. Forged and heat treated load hooks with batch trace ability and stretch indicators

Idling operation

1. Depress the retaining pawl all the way and pull the grip ring towards you.

2. The chain can be adjusted up and down by hand.

3. To terminate the idling: Set the change lever in the down position (See diagram as below). Then, depressing the retaining pawl as far as possible, push the grip ring gently so as to let the pawl engage the outer edge of the retaining plate. Next, grip the grip ring and handle with a single hand and push them while turning them while turning them counter-clockwise. The retaining pawl returns to its original position.

* The specifications on this leaflet may be modified for improvement without notice.

Product code	Capacity (t)	Standard lift (m)	Test load (t)	Pulling Efforts (kg)	Chain fall No.	Load chain Dia. (mm)	Dimensions(mm)					Net Weight (kg)
Product code	Capacity (t)	Standard lift (m)	Test load (t)	Pulling Efforts (kg)	Chain fall No.	Load chain Dia. (mm)	A	B	C	D	E	Net Weight (kg)
VL050	0.50	1.5	0.75	11	1	5	148	128	295	256	45	6.1
VL075	0.75	1.5	1.13	15	1	6.3	148	128	295	256	45	6.9
VL100	1.00	1.5	1.50	20	1	6.3	152	128	310	256	48	7.0
VL150	1.50	1.5	2.25	18	1	7.1	161	148	335	368	52	9.6
VL200	2.00	1.5	3.00	24	1	7.1	168	148	350	368	60	10.1
VL300	3.00	1.5	4.50	38	1	9	191	180	405	368	66	15.9
VL600	6.00	1.5	9.00	39	2	9	191	180	550	368	80	25.7
