0.75 T Ratchet Lever Block Chain Hoist Manual Lever Chain Hoist

Click here to contact
Product details
Chain painting:Galvanzied or Black coating;Package Preview:;
Load chain:G80;Capacity:0.8-6.4 ton;
Port:Tianjin or Guangzhou;Packaging Detail:Standard export packing;
Payment Terms:L/C,T/T,MoneyGram;Lifting height:1.5M-3M;
Model Number:HSH-A;Color:Black, Yellow, Orange, White, Blue;
Brand:OEM;Name:lever hoist;
Place of Origin:Hebei China;Certificate:CE;
Supply Ability:10000.0 Piece/Pieces per Month;
Product Description



VL Type 0.75Ton to 6Ton Lever Hoists G80 Chain Manual Hoist block





Technical Features

1. One touch operation free chain adjustment

2. Grade 80 alloy load chain ISO and GES standard

3. Forged and heat treated load hooks with batch trace ability and stretch indicators

Idling operation

1. Depress the retaining pawl all the way and pull the grip ring towards you.

2. The chain can be adjusted up and down by hand.

3. To terminate the idling: Set the change lever in the down position (See diagram as below). Then, depressing the retaining pawl as far as possible, push the grip ring gently so as to let the pawl engage the outer edge of the retaining plate. Next, grip the grip ring and handle with a single hand and push them while turning them while turning them counter-clockwise. The retaining pawl returns to its original position.



* The specifications on this leaflet may be modified for improvement without notice.



Tested according to EN13157-2004

Product code

Capacity

(t)

Standard lift

(m)

Test load

(t)

Pulling Efforts

(kg)

Chain fall No.

Load chain Dia.

(mm)

Dimensions(mm)

Net Weight

(kg)

A

B

C

D

E

HSH-A075

0.75

1.5

1.13

15

1

6.3

148

128

295

256

45

6.9

HSH-A100

1.00

1.5

1.50

20

1

6.3

152

128

310

256

48

7.0

HSH-A150

1.50

1.5

2.25

18

1

7.1

161

148

335

368

52

9.6

HSH-A200

2.00

1.5

3.00

24

1

7.1

168

148

350

368

60

10.1

HSH-A300

3.00

1.5

4.50

38

1

9

191

180

405

368

66

15.9

HSH-A600

6.00

1.5

9.00

39

2

9

191

180

550

368

80

25.7

Individually proof load tested with individual serial number













Packaging & Shipping





Company Information



Lomba Lifting is a manufacturing and trading company founded in 2002 and located in Foshan City, specializing in the design and manufacture of lifting equipment, equipment and various components.



  Our products have been exported to more than 50 countries and regions in Asia, Middle East, Europe, Australia, Africa and South America for more than 10 years.



  Providing high quality and reliable products and fast and efficient services is our operation priciple. All our products are produced under strict quality control and inspected. Most of our production facilities pass ISO 9001:2008 certified and most of our products pass CE, TUV, GS certified.



   Our business priciple is to highest quality products with the most competitive prices for you.With rich experience in professional service, we can provide measurable advice and support to ensure you get right product with lower cost.



  Any advice or suggestion will receive our most discreet and direct attention. We expect a long term business relation with you and you are welcomed to visit us!
