high quality stainless steel laser welding machine details
Warranty:1 Year,One Year;Certification:ce,ISO;
Single package size:47X37X36 cm;Pulse Width:10/;
Welding mode:Spot/Continuous/Arc/Electro welding;Max. Output Power:40KW;
Selling Units:Single item;Weight:12kg;
Frequency:1-10HZ;Place of Origin:Jiangsu China;
Brand Name:Shanda;Single gross weight:12.0 KG;
Wavelength:/;Single Pulse Energy:/;
Focal Spot Diameter:2;After-sales Service Provided:Online support;
Dimensions:370*155*320mm;Usage:Welding/Molds repairing;
Spot welding diameter:0.4-2.0mm;Condition:New;
Function:Welding or repairing steel;

high quality stainless steel laser welding machine

Product Description

Working Principle

Based on big power inverter technology (AC-DC-AC-DC),we could convert the input current into the DC power of low voltage and high current ,which is what we need for welding.

By using  microcomputer technology,our could :

1)get precise control of welding time

2)make the electric energy act between tungsten electrode and workpiece, in the form of pulsed ARC

3)extremely high temperature ARC make solder wire and the workpiece(made of metal material)melt together

4)thus welding task completed

Technical  Superiority

1)very fast heating speed and little heat when welding:our machine could finish the soldering of workpiece and solder wire in several milliseconds

2)to the base of workpiece ,the less heat, the less warming up for the material except for the welding spot thus no color change and annealing effect happen

3)because of the extremely concentration of output pulse energy,our machine could weld copper and aluminum,which is hard for many many welders

4)high strength of welding,applied to metallurgy welding.the welding area after welding could be done with after-treatment such as milling and filing

5)reasonable power allocation,controlled by microcomputer chip,different workpiece could get perfect power allocation

6)large range of adaptation for voltage:when voltage is changing in 20%,machine could still provide steady power to be working normally

7)convenient to connect to the electricity:equipmented with Quick connector connector

8)easy to carry:light and small

Technology Parameters

Machine modelSDHB-3
Input Power AC220V 50/60HZ
Power 0-4000W
Max Pw40kw
Output1-200A
Frequency1-10HZ
Welding modelspot welding/continuous welding/arc welding /electro welding
Range of welding wire0.3-2.0mm
Weight9kg
Size 370*155*320mm
Advantages



Welding precision:Our SDHB series imitate laser cold welding machine has reached the accuracy(0.1-2.0mm) of laser welding machine

Price:Our cold welding machine is far cheaper than laser welding machine

Welding operation:Our cold welding machine is easier to operate than laser welding machine.You don't need to waste time to learn professional welding skills or employ a welder

Welding functions:Our cold welding machine has more functions  (spot/continuous/arc/resistance welding)

Application&Samples

Excellent heat control,no damage to the workpiece.

Complete metallurgical wld,later under a variety of processing.

Can be used with all types of fillers,dia.0.2mm-1.6mm.

Apply to all kinds of molds,dies,press dies,stainless parts,cast iron parts,aluminum parts,copper/brass/bronze parts.

Recommended Products


Machine ModelSDHB-2SDHB-5
Input PowerAC220V 50HZAC220V 50HZ
Power0-4000W10-1600W
Max Pw40KW>40KW
Output1-200A1-500A
Frequency1-10HZ1-5HZ
Welding ModeSpot/continuous/arc weldingSpot/continuous/resisitance welding
Range of Welding Wire0.3-2.0mm0.1-2.0mm
Weight9kg15.75kg
Size370*155*320mm185*440*320mm
FeaturePrecision repair sheet welding machineColor plate welding without discoloration on the back
