Sompom CCTV Power Supply 12V 30A 360W CCTV 18CH Power Box details
Output Type:Single;Single gross weight:2.4 KG;
Selling Units:Single item;Output Current:30A;
Size:317*220*63mm;Carton:12pcs;
Output Frequency:47-63HZ;Model Number:S-360-12;
Output Voltage:12V DC;Application:CCTV Camera;
Input Voltage:85-264VAC,85-264VAC;Single package size:32.7X23X7.5 cm;
Output Power:301 - 400W;Brand Name:sompom;
Weight:2.15kg;Certification:CE & RoHS&FCC&ISO9001;
Warranty:2 Years;Packaging Detail:1) Vacuum packing 2)Special Protect carton for exporting product. 3)Packing as customer requirement.;
Efficiency:90%;Protections:Short Circuit Overtemp Overload Overvolt;
Channel:18CH;Place of Origin:Guangdong China;

Product Description

1Sompom CCTV Power Supply 12V 30A 360W CCTV 18CH Power Box



+
DC Output DC Voltage: 12V
DC Current :30A
Ripple & Noise: 80MV
DC Adjustable Range: ±10% Rated Voltage
Voltage Tolerance: ±2.0%
Line Regulation: ±0.5%
Load Regulation: ±1%
Setup,Rise Time,Hold Up Time:200ms,50ms, 20ms/230VAC
AC Input AC Voltage Range: 85-264VAC
Frequency Range: 47-63Hz
Efficiency:90%
AC Current: 0.86/115V  0.4A/230V
AC Inrush Current: 20A/115V   40A/230V
Leakage Current< 0.5mA /240VAC
Protection Over-load: 105%-150% hiccup mode,Auto-recovery
Over-voltage: 115%-135% Cut Off the Output,Auto-recovery
Over-temp. : Shut down O/P voltage, Auto-recovery
Environment Working temp.: -10~ +60C°  (Refer to output load derating curve)
Working Humidity:20 ~ 90% RH, non-condensing
Storage Temp.: -10~ +60C°
Storage Humidity: 10 ~ 95% RH
Safety Isolation Resistance:I/P-O/P,I/P-FG,O/P-FG:100M Ohms/500VDC / 25C°/ 70% RH
Withstand Voltage: I/P-O/P:3KVAC I/P-FG:1.5KVAC O/P-FG:0.5KVAC
Safety standards: CE,RoHS,FCC,ISO9001



Related products
+

Features: 110V/220V AC to DC Power Series 3V 5V 6V 9V 12V 13.8V 15V 18V 24V 28V 36V 48V
Model Series Link (View more)
CCTV Power: 12V3A4ch,12V5A4ch,12V5A9ch, 12V10A9ch,12V10A18ch,12V15A18ch, 12V20A18ch,12V30A18ch,
3V Series: 3V5A, 3V10A, 3V20A, 3V30A, 3V40A, 3V60A

5V Series: 5V2A, 5V3.8A, 5V5.5A,5V10A, 5V20A, 5V30A,5V40A, 5V60A

6V Series: 6V10A, 6V20A, 6V30A, 6V40A, 6V50A
9V Series: 9V2A, 9V5A, 9V10A,9V20A,9V30A

12V Series:12V1A, 12V2A, 12V3.2A, 12V5A, 12V8.5A,12V10A, 12V12.5A, 12V15A, 12V16.5A, 12V20A, 12V30A, 12V40A,12V50A.

13.8V Series: 13.8V30A
15V Series: 15V2A,15V5A, 15V10A,15V20A
18V Series: 18V2A, 18V3A, 18V5A, 18V7.5A,18V10A,18V20A

24V Series:24V1A, 24V2A, 24V3A, 24V5A, 24V7.5A, 24V10A 24V15A, 24V20A, 24V25A

28V Series:28V1A, 28V10A
36V Series: 36V2A, 36V5A, 36V10A
48V Series: 48V2A, 48V3A, 48V5A, 48V7.5A,48V10A,48V15A
About Us

SOMPOM is focusing on offering LED switch power, waterproof switch power,rainproof switch power,AC-DC power adapter and CCTV camera power. Withe the over load protection, over voltage protection and high temperature protection. SOMPOM wins customers favor by its high  efficiency, reliability and long life span. Each of the switch power is extremely safe and stable after 5 times testing. All of our powers have the ISO9001,CE,FC,ROHS certification. Our switch powers are widely used in industrial automation field, indoor and outdoor LED lighting, LED lighting engineering.



Our factory



Our certificate



1,Q: What is your MOQ of switch power?
A: Our MOQ is 1 piece

2,Q:How many year warranty of your Led driver?
A: Two years

3,Q: Do you offer sample of power?
A: Yes, We offer free sample, but you need pay the shippment.

4,Q: Do you have switch power factory?
A: Yes, we are OEM & ODM manufacturer in Donguan.

5,Q: Is your power with copper transform or something?
A: We can do with complete copper transform and copper cladding aluminum.

6,Q: Do you have any certification?
A: Yes, we have CE, RoHS, FCC and ISO9001 right now. If you need other certification with large order, We can apply for it.
