mini clinker cement production line / cement making machinery / cement equipments

Supplier: Jiangsu Pengfei Group Co., Ltd.
Region: Jiangsu, China
Contact: Ms Wang Jingjing
Price: $1000000.00 /set
Min. Order: 1 set

Click here to contact

Product details

Port:	Shanghai;	Power(W):	800-20000KW;
Product name:	mini clinker cement production line;	After-sales Service Provided:	Field installation, commissioning and training,Field maintenance and repair service;
Brand Name:	Pengfei;	Key Selling Points:	Long Service Life;
Voltage:	220V, 380V, 6KV, 10KV, etc.;	Fuel:	coal, HFO, natural gas, etc.;
Place of Origin:	Jiangsu China;	Payment Terms:	L/C,D/A,D/P,T/T,Western Union,MoneyGram;
Certification:	ISO9001;	Warranty:	1 Year;
Gearbox for cement production line:	NGC, FLENDER, etc.;	process type:	new type dry process;
finished product of cement equipments:	32.5, 42.5, 52.5 ppc, opc, psc cement;	Supply Ability:	15 Set/Sets per Year mini clinker cement production line / cement making machinery /;
Weight:	10t-2000t;	Condition:	New;
kiln type:	rotary kiln;	Applicable Industries:	Manufacturing Plant;
Warranty:	one year;	Packaging Detail:	nude packing, iron box or wooden box for mini clinker cement production line / cement making machinery / cement equipments;
Dimension(LWH):	Customizable;	raw material of cement production line:	limestone, clay, etc.;
After-sales Service Provided:	Engineers available to service machinery overseas;	Motor for cement equipment:	Chongqing, SIEMES, etc.;

mini clinker cement production line / cement making machinery / cement equipments

High efficient & low consumption dry process rotary kiln cement plant for sale

A. Summary of cement plant for sale:

1. The production method is dry process. A rotary kiln(φ3.5×54m) production line with five-stage cyclone pre-heater and decomposition furnace will be adopted.

2. Production scale and capacity

The production capacity is 1500t/d for clinker, while 500,000t/a for Portland cement when mixed with gypsum.

3. Cement types

The technology and equipment adopted can produce 32.5MP and 42.5MP types of cement in accordance with Chinese Standard GB175-1999. They can be adjusted according to market demand.

4. Raw materials properties chemical composition

Name	L.O.I	SiO2	Al2O3	Fe2O3	CaO	Mgo	K2O	Na2O	SO3	Cl-	Water content
Limestone	39.27	7.17	2.93	1.25	46.94	1.03	0.13	0.23		0.009	0.45
Shale	21.89	36.14	10.39	3.27	22.03	0.8	0.99	0.33		0.015	0.46
Silica	0.10	95.5	1.00	0.20	0.90	0.50
Gypsum		1.40	0.60	0.20	30.52	0.05	0.10	0.10	47.10		18.70
iron	11.5	30.56	22.12	26.91	1.12

5. Fuel

The technical property of mazut:Min. value is ≥9000 kcal/kg(37620kJ/kg)

New five-stage cyclone pre-heater system, high efficiency air girder grate cooler, multi-passage pulverized coal burner, heat temperature fan, electrical dust collector, as well as chain-board elevator, chain conveyor adopted in this cement plant for sale can ensure that the technology is advanced compared to other production lines with the same scale.

6. Main scope of the cement plant for sale:

a. Mechanical Equipment of the cement plant :

1.Limestone crushing & conveying

2..Clay crushing & conveying

3.Clay & iron powder pre-homogenization pile

4.Limestone pre-homogenization pile

5.Raw material dosing station

6.Raw material grinding & exhaust gas treatment

7.Raw meal homogenization silo & feeding kiln

8.kiln outlet

9.Rotary kiln & triple air duct

10.Kiln inlet & clinker conveying
