Portable mma inverter welding machine 250

Supplier: Zhejiang Laoshidun Technology Co., Ltd.
Region: Zhejiang, China
Contact: Mr Wynn Wang
Price: $34.00 /carton
Min. Order: 1 carton

Click here to contact

Product details

Technology:	IGBT;	Packing:	color BOX;
Efficiency:	80% Inverter Welders;	Power(W):	3.5-8.2KVA;
Name:	SINGLE BOARD IGBT INVERTER DC ARC WELDING MACHINE;	Power factor:	0.8;
Warranty:	1 Year;	Place of Origin:	Zhejiang China;
Rated Duty Cycle:	50%;	Usage:	Welding;
Function:	Inverter IGBT Welding Machine;	Certification:	CE Certification;
After-sales Service Provided:	Free spare parts;	Motor Type:	DC MOTOR;
Condition:	New;	Voltage:	220V ±15%;
Payment Terms:	L/C,D/A,D/P,T/T;	Arc Current:	30-200A;
Pilot Arc Current:	30-200AWelding Machine;	Color:	Customized Color;
Port:	FOB NINGBO;	Accessories:	1.2M Earth Clamp;1.6M Welding Clamp;
Packaging Detail:	Kraft box :(365200275MM); 20GP:1400CTNS; 40HQ:3150CTNS;	Dimensions:	365225275mm;
Brand Name:	OEM/LASTON;	Supply Ability:	10000 Carton/Cartons per Month;
After-sales Service Provided:	No overseas service provided;	Pulse Frequency:	50HZ;
Weight:	6.2-8.1KGS;

Portable mma inverter welding machine 250

Product Description

Feature:

1.Use powerful IGBT switches and advanced inverter control technology.

2.Excellent arc characteristics and good welding performance.

3.With anti-stick,hot start,arc force,strong compensation capability.

4.With Auto protection functions of overcurrent and overheat.

5.Single phase,portable,fan-cooled,IGBT inverter welder,in this welding process,an electric arc is created between a coated consumable electrode and the work piece to be welded,causing the parent material to be fued together and the electrode to be melt.

ITEM	XP-120	XP-140	XP-160	XP-180	XP-200
POWER VOLTAGE(V)	220V 50HZ	220V 50HZ	220V 50HZ	220V 50HZ	220V 50HZ
RATED INPUT CAPACITY(KVA)	3.5	5.3	6.2	7.2	8.2
RATED INPUT CURRENT(A)	16	24	28	33	37
RATED OUTPUT(A)	120A/24V	140A/25.6V	160A/26.4V	180A/27.2V	200A/28V
OUTPUT CURRENT RANGE(A)	30-120	30-140	30-160	30-180	30-200
NO-LOAD VOLTAGE(V)	67	67	67	67	67
DUT CYCLE(%)	30	30	30	30	30
EFFICIENCY(%)	85	85	85	85	85
POWER FACTOR	0.73	0.73	0.73	0.73	0.73
INSULATION CLASS	F	F	F	F	F
PROTECT CLASS	IP21S	IP21S	IP21S	IP21S	IP21S
USABLE ELECTRODE(mm)	1.6-2.5	1.6-3.2	1.6-4.0	1.6-4.0	1.6-5.0
DIMENSION(mm)	365200275	365200275	365200275	365200275	365200275
WEIGHT(kg)	4.5	5	5.2	5.5	6

Package & Payment

Factory standard packing is kraft box with left and right foam,and if your quantity is enough to 100 pcs then we can make your brand on the package(OEM design package),and also you can choose the other package which like: honeycomb box,plastic box,aluminum box,colour box(MOQ is 500 pcs) and so on.
