High Efficiency 1.0 Micron PP Filter Cartridge for Stainless Steel Fruit Juice Filter

Supplier: Hangzhou Tianshan Precision Filter Material Co., Ltd.
Region: Zhejiang, China
Contact: Ms Fiona Li
Price: $1.00 / >=10 pieces
Min. Order: 10 pieces

Click here to contact

Product details

Application2:	Fine Chemicals;;	Certificate:	FDA;SGS,etc.;
Cage, Inner core, Adapter:	PP;	Supply Ability:	500000 Piece/Pieces per Month;
Packaging Detail:	1pc / 1 polybag/ 1 small carton; 12 or 20 pcs in one big carton;	Model Number:	Stainless Steel Fruit Juice Filter;
Product type:	1.0 Micron PP Filter Cartridge for Stainless Steel Fruit Juice Filter;	Place of Origin:	Zhejiang China;
After-sales Service Provided:	No overseas service provided;	Processing:	Filter;
Dimension(LWH):	7.57.530;	Adapter:	DOE, 226, 222, etc;
Certification:	SGS,FDA,etc;	Weight:	0.32kg/10inch;
Condition:	New;	Micron:	0.1-100um;
Voltage:	220;	Application1:	Pharmaceuticals;;
Brand Name:	TS Filter;	Delivery Detail:	3-15 days;
Material:	PP Membrane;	Processing Types:	Juice;
Port:	Shanghai;	Warranty:	2 years;
Length:	10/20/30/40inch;	Application3:	Food&Beverage,etc;
Power(W):	200;	Payment Terms:	L/C,T/T,Western Union;

High Efficiency 1.0 Micron PP Filter Cartridge for Stainless Steel Fruit Juice Filter

Product Description

These Polypropylene(PP) membrane filter cartridges are made of 100% high quality polypropylene material which provides excellent chemical compatibility and flushed with high purity water to remove manufacturing debris.

A broad range of efficiencies with beta ratios of 50 to 5000 provides the flexibility to many applications inculding prefiltration/coarse filtration and absolute filtration/final filtration.

High Efficiency 1.0 Micron PP Filter Cartridge for Stainless Steel Fruit Juice Filter

Features & Benefits:

Absolute & Nominal Efficiency:0.1, 0.2,0.45, 0.65, 1, 3, 5, 10, 20, 30, 40, 50,100microns
100% high quality polypropylene material, wide compatibility
Free of surfactants, resins, binders and adhesives.
All components meet USP specifications for Class VI
Clean and flushed with Pyrogen-free water
Effective Filtration Area: 0.65 M2 per 10 inch

Technical Specification:

Material of construction
Filter media	High Quality Polypropylene(PP) Membrane
Core,End Cap,Cage	Polypropylene(PP)
Support layer	Polypropylene(PP)
Sealing Method	Thermal Bonding
O-rings/gasket	Silicone/Nitrile/EPDM/Teflon/Viton
End Cap Configurations	222/Flat, 222/Fin, 226/Flat, 226/Fin,DOE,SOE,etc
Dimensions
Outer Diameter	69mm(2.75'')
Inner Diameter	33mm(1.30'')
Length(based on DOE adapter)	10''/20''/30''/40'',5'',others
Filtration Area(m2)	0.65m2 per 10''
Operating conditions
Normal flow direction	4.2bar(60 psi) at 25°C(77°F)
Reverse flow direction	2.1bar(30 psi) at 25°C(77°F)
Normal operating temperature	up to 55°C(149°F)
Max operating temperature	85°C(172°F) at P≤1.0bar(14psi)
PH value compatibility	1-13
Particular removal efficiency(%)	Nominal Efficiency >90% Absolute Efficiency ≥99.99%
