High Efficiency High Quality PP Enol Filter Cartridges for Wine/Wine/Beverage Processing
- 3.00 piece
| brand: | TS filter | Mechanical test report: | if |
| Packaging Details: | Export standard packing: 1 filter element/1 polybag/1 small carton; 12 or 20 pieces in a large carton | Core Components Warranty: | Not available |
| Application 2: | Fermentation broth; fine chemicals; | Core components: | polypropylene |
| Video external inspection: | Not available | Showroom location: | not any |
| Supply capacity: | 500000 pieces/year | Dimensions (L*W*H): | 33*7.5*7.3 |
| weight: | 0.5kg | External support: | Polypropylene cage |
| Packaging Preview: | Certification: | Chief Executive; ISO9001 | |
| model: | polypropylene | length: | 5''/10''/20''/30''/40'' |
| strength: | 800w | Application 1: | Medicines; Bees; Biological Products; |
| Processing: | filter | Application 4: | Semiconductors, liquid crystal displays; optical discs. |
| Health status: | new | payment terms: | L/C,D/P,T/T,Western Union,Paypal |
| Support layer: | polypropylene | microns: | 0.1um/0.2um/0.45um/1um/5um/20um/40um |
| Local service location: | not any | Warranty: | unavailable |
| Filter media: | Polypropylene film | Marketing Type: | Hot Products of 2019 |
| Voltage: | 220V | port: | Shanghai |
| Application 3: | Food and beverages, wine, beer, mineral water; | Kernel: | polypropylene |
| Processing Type: | Alcohol | place of origin; place of origin: | Zhejiang, China |
| After Warranty Service: | Online support | Applicable industries: | Mechanical Repair Shops, Food and Beverage Plants, Farms, Retail, Energy and Mining, Wine Filters |
High Efficiency High Quality PP Enol Filter Cartridges for Wine/Wine/Beverage Processing
Polypropylene (PP) membrane filters offer high flow rates and dirt holding capacity, 100% premium polypropylene construction with excellent chemical compatibility,
Its thermally bonded construction ensures minimal extractability, and its high filtration efficiency makes it an excellent choice for a variety of industrial applications.
|
absolute rating |
Imported polypropylene film is available Absolute rating filtering. |
|||||||||||||||
|
complete polypropylene structure |
Made of 100% high quality polypropylene material |
|||||||||||||||
|
Broad chemical compatibility |
Available for pH from 1 to 13 |
|||||||||||||||
|
No media migrated to process fluid |
All materials passed migration test |
|||||||||||||||
|
Effective filter area |
0.65 square meters per 10 inches |
|||||||||||||||
|
Material
|
Filter Media: Polypropylene Membrane |
|||||||||||||||
|
Support Layer: Polypropylene |
||||||||||||||||
|
Inner core: polypropylene/SUS304 |
||||||||||||||||
|
Outer Support: Polypropylene cage |
||||||||||||||||
|
Cartridge size (nominal)
|
Outer Diameter: 69 mm (2.75 in) |
|||||||||||||||
|
Inner Diameter: 33mm (1.30") |
||||||||||||||||
|
Length: 10"- 254mm |
||||||||||||||||
|
20"- 508mm |
||||||||||||||||
|
30"-762 mm |
||||||||||||||||
|
40"- 1016mm *(Length based on DOE adapter) |
||||||||||||||||
|
Cartridge Purity
|
Free of surfactants, resins, binders and adhesives |
|||||||||||||||
|
Standard: Wash and rinse with pyrogen-free water |
||||||||||||||||
|
Flush: Up to 17-18MΩ.cm, minimum throughput |
||||||||||||||||
|
Table 1: Typical Water Flow Rate (10") |
|
|||||||||||||||
|
typical application |
Pharmaceuticals; Bees; Biological Products; Fermentation Broth; Fine chemicals; food and beverages, wine, beer, Mineral Water; Semiconductors, Liquid Crystal Displays; Optical Discs |
|||||||||||||||
|
Table 2: Liquid retention Scoring (um) test |
|
|||||||||||||||
|
Operating conditions
|
Normal operating temperature: up to 60°C (140°F) |
|||||||||||||||
|
Maximum operating temperature: 80°C (172°F) at P≤1.0 bar (14psi) |
||||||||||||||||
|
maximum. Different pressures: Normal flow 4.2 bar (60 psi) at 25°C (77°F); Reverse flow direction 2.1 bar (30psi) at 25°C (77°F) |
||||||||||||||||
|
PH Compatibility: 1-13 |
||||||||||||||||
|
disinfect
|
Steam sterilization at 121±2℃ for 30 minutes |
|||||||||||||||
|
cumulative time: 15 hours; or rinse with hot water at 82°C (180°F) 30 minutes at P≤1.0 bar (14psi) - recommended. |
||||||||||||||||
|
Material Safety
|
Complies with current FDA and 2002/72/EC standards |
|||||||||||||||
|
Endotoxin: <0.25 EU/ml |
||||||||||||||||
|
Extractables: 0.03g/10" |
||||||||||||||||
|
Table 3: 100% Integrity Testing |
|
|||||||||||||||
order information
| grade | product | Micron | adapter | length | O-rings/gaskets | |
| H-Chemistry | IPP | 010-0.1um | U.S. Department of Energy | 10-10" | S-Silica gel; N-Nitrile | |
| Electronic and electrical | 020-0.20um | CN-226/FIN | 20-20" | E-EPDM; T-PTFE (encapsulated) | ||
| P-Pharma | 045-0.45um | BN-222/fin | 30-30" | V-Fluoroelastomer | ||
| F- Food and Beverage | 100-1.00um | BF-222/Flat seal | 40-40" | How to order? - Example | ||
| CF-226/Flat Seal | 05-5" |
Pharmaceutical grade; Micron: 0.5um; Length: 10" Adapter: DOE; Gakset: Silicone. The selection code is: PIPP050AA10S |
||||
| EN-222 Tri-lock lugs/Fin | Other-XX | |||||
1.24 hours response
We will respond to any request from customers within 24 hours, saving you time and labor.
2. Supporting system
The system consists of a claim system, a technical support system, an inquiry system and an order tracking system. The system will provide a full range of after-sales services.
3. Free training
We offer free training to all customers and dealers. Training will give you a solid understanding of our products and make your job easier.
4. Free storage area
We provide our customers with free storage area for mixed loading purposes.
