SMW MULTI VESSEL DYEING MACHINE

SMW 5kg to 15kG Fully Automation Polyester Cone Dyeing machine
We have all the requisite facilities to manufacture and offer a technologically advanced range of Small Package Dyeing Machine / Multi Package / Pilot Yarn Dyeing Machine. Manufactured using quality materials, these are appropriate for dyeing of loose fibers, tops, tows, yarn packages and yarn beams with suitable material carriers.

• Standard manufacturing and working specifications:
• - Available nominal capacity: 1 to 30 kg
• - Maximum pressure: 5,0 Bar
• - Maximum temperature: 160°C
• - Working temperature: 90 - 140°C
• - Made of stainless steel 316L for all the parts in direct contact with the dyeing liquor
• - Waterproof motors
• - Waterproof electrical components
• - 3-level security system
• - Magnetothermic protections
• - Indirect heat exchanger tested for a maximum pressure of 12 Bar
• - Heating gradient: 5°C/minute (from 20 to 80°C – steam pressure: 6,0 Bar)
• - Cooling gradient: 3°C/minute (from 130 to 108°C – water temp,: 15°C, pressure: 2,5 Bar)
• - Manual opening and closing of lid
• - Manual locking system with security device

Additional Information:

• Item Code: SMWDYAP1
• Production Capacity: 2IN MONTH
• Delivery Time: 20 DAYS
