Hthp Vertical Tubular Cone Dyeing Machine

Package Yarn Dyeing Machine 60kg for cones or hanks. The dyeing machine is used for dyeing yarn at high temperature and high pressure. Our expert technicians ensure that it is manufactured using fine grade material, procured from the most authentic vendors of the industry. he body of the machine is fabricated using high grade stainless steel in order to assure durability and resistance to corrosion. We fabricate these machines using premium quality raw material that is procured from the most credible vendors of the industry.

Main Features:

1. Capacity range from 1 kg to 500 kg
2. Very low liquor ratio from 1:3 to 1:5
3. Loading up to 30% possible
4. Savings of water, chemical, heat & electrical energy
5. Coil type heat exchanger for efficient and fast heat transfer
6. Design ensures complete drain of liquor
7. Pneumatic cylinder lift door with Heavy Clamp locking system
8. Hydraulic safety locking for door
9. Large Saving of capital and operational cost


Application:

1. Yarn Packages
2. Zipper Tapes
3. Small width Fabrics
4. Loose fibres


Advantages:

1. Compact arrangement of SMW turbo pump, heat exchanger and piping is the main key to floor space saving
2. Ultra Low MLR of 1:3, consumes less dyestuff, chemicals, steam, water & produces less effluent discharge, hence it''s ECO friendly & reduces the Production Cost
3. Inverter driven turbo pump for variable flow control; saves upto 40% power consumption hence more Energy Efficient
4. HT drain at 130°C for oligomers elimination during polyester dyeing process
5. Variable loading with dummies maintains constant MLR & Flow Rate
6. Excellent dyeing result and levelness, reduces yarn loss
7. Water level, pressure, distinctive temperature multiple safety interlock, ensure operational safety

Additional Information:

• Item Code: SMDYTU1
