SBG-15-FL SBC rail and slider carriage SBG15FL for CNC rails

Supplier: Tianjin Xurui Hengda International Trading Co., Ltd.
Region: Tianjin, China
Contact: Mr Xianliang Tian
Price: $35.00 / 10 - 49 units
$30.00 / >=50 units
Min. Order: 10 units

Click here to contact

Product details

Health status:	new	feature:	smooth motion
Matching guide rail:	SBG15-1500L Korean SBC linear guide rail is suitable for SBG15FL	model:	SBG15FL Korean SBC guide rail
type:	SBI seriesSBI55FL SBG25SLL	Material:	Bearing steel, GCR15
SBC sliders for rails:	SBG15FL	Origin:	Chungcheongbuk-do, South Korea
product name:	SBG-15-FL original Korean SBC linear guide block	Supply capacity:	200 units per month
port:	any port	guide:	SBG25-1000L
Performance:	high performance	application:	High-speed transmission device for automation equipment
Packaging Details:	standard packaging	payment terms:	L/C, T/T, Western Union, MoneyGram
Linear guide applications:	Spare parts for CNC machine tools SBG15-FL SBC	Warranty:	6 months
brand:	small computer company	Applicable industries:	Manufacturing plants, machinery repair shops, food and beverage plants, retail, energy and mining

SBG-15-FL SBC rail and slider carriage SBG15FL for CNC rails

Block SBG-15-FL in stock

SBG15FLL Korean SBC linear guide block and guide rail system SBI15FL

SBC rail and carriage/slider features:
1: The friction coefficient is low, which can completely resist the obstacles of high-speed transmission. At the same time, it also produces high-yield, high-frequency mechanical equipment to reduce power loss and prolong service life.

Second: The coefficient of friction is reduced to 1/50 to achieve micro-displacement and precise positioning.

Three: Easy installation without affecting high strength and high precision.

Four: Compared with Japanese high-end products, the cost performance is as low as 30%-40%. According to different usage specifications, Kemeixin has carried out all-round stocking, so that supporting engineering customers can fully realize zero inventory management.

Advantages of SBC linear guide system:
1. High cost performance
SBC linear guides are very economical in all aspects, especially in terms of simple design, high structural strength and localization of products.

2. Complete variety
All standard models are available from stock.

3. Accurate positioning accuracy
Due to the small difference between dynamic and static friction, the SBC guide rail reduces the friction coefficient to 1/50. Therefore, precise positioning in response to small displacements can be achieved.

4. Save production cost and power consumption
Due to the small coefficient of friction of the SBC guideway, the drive unit can be miniaturized and high-speed motion can be provided. Therefore, SBC guide rails can be used to produce high-performance machinery while reducing power loss.

5. Maintain high precision for a long time
Long-term, wear-free, high-precision operation is achieved by reducing rolling friction.

6. Simple installation
SBC rails are simply bolted to maintain high precision and carry the same load in all four directions.

7. Improve the reliability of the machine Estimate the life of the machine according to the number of reciprocations to improve the reliability of the machine.

Model

installation size

block size

watt

Second

Mounting screw holes

Temperature ±1

Grease nozzle

Second

Medium

Nitrogen

*Second quarter

SBG15FL	twenty four	47	60.8	3	38	30	M5	M4	38.8	7.2	twenty one	4	5.5	4.5	4.5	M4x0.7	ø3.5
SBG20FL	30	63	77.2	3.5	53	40	M6	M5	50.8	9	26.5	7	12	7	5	M6x0.75	ø5.5
SBG20FLL	30	63	93.2	3.5	53	40	M6	M5	66.8	9	26.5	7	12	7	5	M6x0.75	ø5.5
SBG25FL	36	70	86.9	6.5	57	45	M8	M6	59.5	10	29.5	8.2	12	8.1	5.5	M6x0.75	ø5.5
SBG25FLL	36	70	106.4	6.5	57	45	M8	M6	79	10	29.5	8.2	12	8.1	5.5	M6x0.75	ø5.5
SBG30FL	42	90	100	7	72	52	M10	M8	70.4	12	35	8.5	12	8.5	5.5	M6x0.75	ø5.5
SBG30FLL	42	90	122.5	7	72	52	M10	M8	92.9	12	35	8.5	12	8.5	5.5	M6x0.75	ø5.5
SBG35FL	48	100	112.6	7.5	82	62	M10	M8	80.4	13	40.5	8	12	8	6	M6x0.75	ø5.5
SBG35FLL	48	100	138.1	7.5	82	62	M10	M8	105.9	13	40.5	8	12	8	6	M6x0.75	ø5.5
SBG45FL	60	120	140.3	10	100	80	M12	M10	98	15	50	10	16.5	10	8	PT1/8	ø8.5
SBG45FLL	60	120	172.3	10	100	80	M12	M10	130	15	50	10	16.5	10	8	PT1/8	ø8.5
SBG55FL	70	140	166.8	13	116	95	M14	M12	118	number 17	57	12	16.5	10.5	10	PT1/8	ø8.5
SBG55FLL	70	140	204.8	13	116	95	M14	M12	156	number 17	57	12	16.5	10.5	10	PT1/8	ø8.5
SBG65FL	90	170	195.2	17.5	142	110	M16	M14	147	twenty three	72.5	15	16.5	12	10	PT1/8	ø8.5
SBG65FLL	90	170	255.2	17.5	142	110	M16	M14	207	twenty three	72.5	15	16.5	12	10	PT1/8	ø8.5

For other series and models, please contact us!

Machining centers, injection molding machines, machine tools, presses, precision machining
Centers, automation, heavy cutting machines, transport equipment.
