Programmable Environmental Climate Chamber Humidity Temperature Test Chamber Climate Temperature Test Chamber Humidity Test Equipment Price

Supplier: Dongguan Hongjin Test Instrument Co., Ltd.
Region: Guangdong, China
Contact: Mr gavin Lee
Price: $199.00 /set
Min. Order: 1 set

Click here to contact

Product details

payment terms:	L/C, Western Union, D/P, D/A, T/T, MoneyGram	Heating rate/min:	4 degrees
Temperature fluctuations:	±0.5℃	Packaging Details:	Fumigation-free export wooden box
Humidity range:	20%~98% relative humidity	product name:	Constant temperature and humidity test chamber
Origin:	Guangdong, China	model:	Hua Jie
temperature range:	-20°C, -40°C, -60°C, -70°C optional	color:	customer request
power supply:	AC 220V 50/60Hz	Internal Dimensions W x H x D (cm):	40x50x40 (customized)
brand:	Hong Jin	Cooling rate/min:	1 degree
Package preview:		Temperature distribution accuracy:	±2.0℃
strength:	Electronics	Warranty:	1 year
Customization support:	OEM, ODM, OBM

Product Description

Programmable environmental climate chamber temperature and humidity test chamber climate temperature and humidity test equipment price The equipment is used to test the performance of materials in various environments, and to test the heat resistance, cold resistance, dryness resistance and humidity resistance of various materials. It is suitable for quality inspection of products such as electronics, electrical appliances, mobile phones, communications, instruments, vehicles, plastic products, metals, food, chemicals, building materials, medical care, and aerospace.

Specification

model	TH-80 (A~F)	TH-150 (A~F)	TH-225 (A~F)	TH-408 (A~F)	TH-800 (A~F)	TH-1000 (A~F)
Internal Dimensions W x H x D (cm)	40×50×40	50×60×50	60×75×50	80×85×60	100×100×80	100×100×100
External Dimensions W x H x D (cm)	120×165×115	130x170x125	140x185x130	165x195x155	185x200x175	190x210x185
temperature range	Low temperature: A: +25°C, CB: 0°C, C: -20°C, D (150°C): up to 40°C, E: 60°C, F: high temperature -70°C, 100°C
humidity range	20%-98% RH(10%-98% RH) : (5%-98% RH is a special selection condition)
Temperature and humidity analysis accuracy/distribution accuracy	0.1℃ 0.1% relative humidity/±2.0℃ ±3.0% relative humidity
Temperature and humidity control accuracy	±0.5℃, ±2.5%RH
heating/cooling time	Heating up about 4.0°C/min; cooling down about 1.0°C/min
interior and exterior materials	The inner and outer cabinets are made of SUS304# stainless steel plate (baking paint is optional).
Insulation Materials	High temperature resistant high density vinyl chloride formate foam insulator material
cooling system	Air-cooled/single-stage compressor (-20°C); two-stage compressor (-40°C-70°C)
safety device	No fuse switch, compressor overload protection, refrigerant high and low pressure protection, over-humidity and over-temperature protection, fuse, fault warning system, water shortage alarm protection
Accessories	Operating hole built-in glass door (optional), recorder (optional), observation window, 50mm test hole, PL box light, partition, dry and wet ball gauze, casters, horizontal tripod
power supply	AC220V 50/60Hz & AC380V 50/60Hz3
weight (approximately)	150 kg	180 kg	250 kg	350 kg	500 kg	520 kg
