Wuling Hongguang Mini EV motor 40KW with control unit electric drive full ev complete conversion kit
- 1200.00 2 - 9 pieces
- 1100.00 10 - 99 pieces
- 1000.00 100 - 99999999 pieces
- 700.00 >=100000000 pieces
| rated power: | 20 kW | Peak power: | 40 kW |
| product name: | EV conversion kit | engine: | Permanent Magnet Synchronous Motor |
| payment terms: | wire transfer | Speed (rev/min): | 16000 rpm |
| Voltage: | 220V | Vehicle Type: | Battery |
Wuling MINI EV Concealment Kit Spec Sheet
Product Description and Specifications
Below, starting from the right
Bottom right: three-phase variable frequency motor drive,
Upper right: air conditioner compressor
Second from the right: three-phase motor
Right 3 open: battery charger,
Right 3 Next: DC-DC
Left: LiB
The 2020 Baojun E300 has 2-seater and 3-seater versions. In terms of body size, length: 2625 width: 1647 height: 1588 mm, and the wheelbase has reached 1750 mm. Curb weights range from 920 to 940 kg. Tire size 145/70 R12
The motor series is TZ154X140 produced by Zhejiang Fangzheng Motor Co., Ltd. with a power of 40Kw (54Ps)/150Nm and a maximum speed of 100km/h
|
Technical Supportpectoralis |
|
|
Model |
TZ154X140 |
|
Powertrain Dimensions |
251*255*250mm |
|
Peak torque/speed (Nm/rpm) |
150@0-9000rpm |
|
Peak power (kW) |
40KW@ |
|
Working Voltage/Rated Voltage (V) |
328V |
|
Rated power (kW) |
20 |
|
Rated torque (Nm) |
40 |
|
Maximum speed (rpm) |
9000 rpm |
|
degree of protection |
IP67 |
|
overall efficiency |
89 % / 93 % peak |
|
cooling method |
natural air cooling |
|
weight |
25 kg |
Permanent Magnet Synchronous Motor (PMSM)
