LORA SERVER SOFTWARE LORAWAN WALL MONITOR OZONE O3 CARBON MONOXIDE CO AMMONIA NH3 HYDROGEN H2 METHANE CH4 GAS SENSOR

Supplier: Honde Technology Co., Ltd.
Region: Beijing, China
Contact: Mr Marvin Li
Price: $75.00 / 1 - 9 pieces
$70.00 / 10 - 99 pieces
$60.00 / >=100 pieces
Min. Order: 1 piece

Click here to contact

Product details

temperature range:	-10~50℃	describe:	Custom Gas, Wall Mounted Gas Sensors
brand:	Hongde Technology	usage:	gas detection
Origin:	Beijing China	Installation type:	Wall-mounted
application:	Power plant/paint room/gas station/chemical plant/liquefied petroleum gas station	theory:	Conversion of gas volume to electrical signal
output:	RS485/4-20mA/0-5V/0-10V/LCD,RS485/4-20mA/0-5V/0-10V/LCD	Package preview:
product name:	Wall Mounted Gas Sensor	Supply capacity:	1000 pieces per month
power supply:	DC10-30V	payment terms:	Western Union, T/T, MoneyGram, PayPal
port:	Tianjin harbor	Warranty:	1 year below normal
model:	RD-GD-WM-03	Wireless module:	GPRS/4G/WIFI/LORA/LORAWAN
Cloud server and software:	support	type:	Smoke detector, carbon dioxide sensor, humidity sensor, air quality sensor, gas sensor, combustible gas, explosive gas
shell material:	IP65	Packaging Details:	carton
MOQ:	1

Product Description

Measurement parameters
size	859040mm
shell material	IP65
screen size	LCD screen
oxygen	Measuring range	solve	accuracy
oxygen		0-25% volume	0.1 % volume	±3% full scale
hydrogen sulfide	Measuring range	solve	accuracy
		0-100 ppm	1 ppm	±3% full scale
		0-50ppm	0.1 ppm	±3% full scale
carbon monoxide	Measuring range	solve	accuracy
		0-1000 ppm	1 ppm	±3% full scale
		0-2000ppm	1 ppm	±3% full scale
CH4	Measuring range	solve	accuracy
CH4		0-100%LEL	1%LEL	±5% full scale
nitrogen dioxide	Measuring range	solve	accuracy
		0-20ppm	0.1 ppm	±3% full scale
		0-2000ppm	1 ppm	±3% full scale
sulfur dioxide	Measuring range	solve	accuracy
		0-20ppm	0.1 ppm	±3% full scale
		0-2000ppm	1 ppm	±3% full scale
hydrogen	Measuring range	solve	accuracy
		0-1000 ppm	1 ppm	±3% full scale
		0-40000ppm	1 ppm	±3% full scale
Ammonia	Measuring range	solve	accuracy
		0-50ppm	0.1 ppm	±5% full scale
		0-100 ppm	1 ppm	±5% full scale
PH3	Measuring range	solve	accuracy
PH3		0-20ppm	0.1 ppm	±3% full scale
O3	Measuring range	solve	accuracy
O3		0-100ppm	1 ppm	±3% full scale
Other gas sensors	Support for other gas sensors
go out	RS485/4-20mA/0-5V/0-10V/LCD
voltage	DC 10~30V
Wireless module and supporting server and software
wireless module	GPRS/4G/WIFI/LORA/LORAWAN (optional)
Matching Servers and Software	We can provide supporting cloud server and software, and you can see real-time data on the PC side.

detailed image

Product advantages

●IP65 level protection

●Accurate measurement

●Waterproof and moisture-proof

● Strong anti-interference

●DC 10~30V power supply

●RS485/4-20mA/0-5V/0-10V/LCD

● One year warranty

Data Display

LED displayYou can choose according to your needs or we provide matching cloud servers and software, and you can see real-time data on the PC side.

scope

Sulfur dioxide Ammonia Carbon monoxide Oxygen Nitrogen dioxide Methane Hydrogen sulfide Temperature Hydrogen Humidity●Customize the parameters you need●Other

can be singlegas module, can also be a combination ofMultiple gas modules.

Audible alarm

If the measured value is higher or lower than the set value, there will be aSound and light alarm prompt.

Output and supporting software

Output: RS485/4-20mA/0-5V/0-10V/LCD

Connect wireless modules, including WiFi GPRS 4G Lora Lorawan, we can also provide supporting servers and software to view real-time data on the PC side
