Original Teledyne Oxygen Sensor C06689-B1 ,B-1

B-1
Oxygen Sensor

C6689-B1

General purpose percent oxygen analysis requiring fast response (90% in less than 7 seconds).

Use B-3 or C-3 where longer life is required and response time is relatively unimportant. Can be used to spot check smoke.

B-2C
Oxygen Sensor

C6689-B2C

For general purpose trace O2 analysis of noble gas and hydrocarbon streams. The lower end of the range is 0-10 ppm.

Available for CO2-free gas streams containing highly mobile gases such as H2, He and Ethylene.

real-time tracking
Oxygen Sensor

B71875

A special patented structure provides rapid recovery to low PPM levels during initial battery installation by reducing recovery time from hours to minutes. The lower end of the range is 0-10 ppm.

For the analysis of trace O2 in inert gas and hydrocarbon streams.

B-2CXL
Oxygen Sensor

C6689-B2CXL

Specially qualified B-2C sensor for operation in XL model analyzers. The lower end of the range is 0-1 ppm.

Available for CO2-free gas streams containing highly mobile gases such as H2, He and Ethylene.

B-3
Oxygen Sensor

C6689-B3

Percentage O2 analysis, the best compromise between long life and fast response.

Can be used to spot check smoke.

B-4C
Oxygen Sensor

C14613-B4C

Trace O2 cell specially designed for Model 317EXI.

Performance is the same as B-2.

B-5
Oxygen Sensor

C45091-B5

Special application battery (non-standard) requiring long life and moderately fast response; B-5 has 3 times the life of B-3.

An amplifier gain of 3 times that of B-3 is required. Life expectancy is 36 months in air.

B-5F
Oxygen Sensor

C45091-B5F

Special application batteries (not standard) that require long life and moderately fast response in the presence of CO2.

Use type F (acid electrolyte). A higher amplifier gain than normal is required. The 90% response time is 13 seconds. Life expectancy in air is 6 months.

B-7
Oxygen Sensor

C45091-B7

Special application units (non-standard) that require fast response; B-7 lasts 3 times longer than B-1 battery.

An amplifier gain of 3 times that of B-1 is required. Life expectancy in air is 24 months.

B-7F
Oxygen Sensor

C45091-B7F

Special application batteries (not standard) that require a moderate lifetime and fast response in the presence of CO2.

A higher amplifier gain than normal is required. The 90% response time is 7 seconds. Life expectancy in air is 3 months.
