100g 150g 300g 500g Orthodontic Dial Tensioner Force Gauge
- 18.00 piece
Registered Supplier
Direct Contact
Inquiry via Message
Product Details
| Model Number: | ATN-3; | G.W.: | 2 sets 0.5kg; |
| Brand Name: | ALIYIQI; | Size: | 29*19*15CM; |
| Package Type: | One set in a black plastic box, then put in the cardboard box; | Single gross weight: | 1 KG; |
| Single package size: | 10X8X5 cm; | Selling Units: | Single item; |
| Place of Origin: | Zhejiang China (Mainland); | Color: | black; |
| Delivery Detail: | 0 days after payment; | MOQ: | 2 sets; |
| Division value: | 0.1N; | Measuring range: | 0.6-3-0.6; |
| Max. measured value: | 3N; |
100g 150g 300g 500g Orthodontic Dial Tensioner Force Gauge
Function:
Tension meter relay connections to apply pressure, electronic switches, micro-switches, valves, spring widening pressure, dial spindle pressure measurement equipment,automatic
telephone equipment connections and pressure mechanical pressure armature, tape
recorders buffer pressure point of contact pressure and other precision pressure, tension tests.
Characteristics:
- Simple to use
- Refined appearance
- Testing as long as needed to promote stylus test objects from the static position of the need to be mobile.
- Tension along allows clockwise direction along an anti-clockwise test, but it always stylus arm and push in the direction of the vertical tension.
| Types | Max. measured value | Division value | Measuring range |
| Units:N | |||
| ATN-0.05 | 0.05N | 0.002N | 0.01-0.05-0.01 |
| ATN-0.1 | 0.1N | 0.005N | 0.02-0.1-0.02 |
| ATN-0.3 | 0.3N | 0.01N | 0.06-0.3-0.06 |
| ATN-0.5 | 0.5N | 0.02N | 0.1-0.5-0.1 |
| ATN-1 | 1N | 0.05N | 0.2-0.1-0.2 |
| ATN-1.5 | 1.5N | 0.05N | 0.3-1.5-0.3 |
| ATN-3 | 3N | 0.1N | 0.6-3-0.6 |
| ATN-5 | 5N | 0.2N | 1-5-1 |
| Units:G | |||
| ATG-5 | 5g | 0.2g | 1-5-1 |
| ATG-10 | 10g | 0.5g | 2-10-2 |
| ATG-30 | 30g | 1g | 6-30-6 |
| ATG-50 | 50g | 2g | 10-50-10 |
| ATG-100 | 100g | 5g | 20-100-20 |
| ATG-150 | 150g | 5g | 30-150-30 |
| ATG-300 | 300g | 10g | 60-300-60 |
| ATG-500 | 500g | 20g | 100-500-100 |
Pictures:
