Dongguan factory price AIXIN 25M optical fiber audio toslink spdif output DLR2160
- 0.80 1000 - 9999 pieces
- 0.76 10000 - 19999 pieces
- 0.72 20000 - 49999 pieces
- 0.64 >=50000 pieces
Registered Supplier
Direct Contact
Inquiry via Message
Product Details
| Types of: | SPDIF connector | describe: | spdif fiber optic toslink connector |
| payment terms: | wire transfer | application: | circuit board |
| model: | DLR2160 | port: | Hongkong |
| Supply capacity: | 2,000,000 pieces per month | gender: | female |
| Fiber-coupled optical output: | -21～-15dBm | Certificate: | ROHS Directive |
| Operating transfer rate: | 16Mbps | Package: | tray |
| Packaging Details: | Tray 100 100 pcs 13.5*27*3 cm inner box 20 pcs tray/box 2000 pcs 29*29*22 cm outer box 2 pcs inner box/outer box 4000 pcs 60*31*25.8 cm | Operating Voltage: | 2.7~5.5v |
| place of origin; place of origin: | Guangdong, China | Gray or black shutter: | Two plastic fixing feet |
| brand: | Aisin |
illustrate
The light receiving unit is a standard packaged product with connectors and photoelectric
Component packaged with PD and I/V amplifier IC. Cell function changes optical signal
into an electrical signal.
The device operates at +3~+5V and the input signal is TTL compatible. The DLR2160 has
The maximum operating speed is 25 Mbps.
application
· Audio equipment
· Digital optical data link
· Medical PhD
· Sound card
fiber optic connector receiver
