2KW 3.6KW 12V 24V Single Phase Grid Connected MPPT Hybrid Solar Wind Pump Inverter for Solar Power System

  • 315.00 1 - 9 pieces
  • 273.00 10 - 99 pieces
  • 245.00 >=100 pieces
Min. Order: 1 piece FOB PRICE
Contact Supplier View Company
Registered Supplier Direct Contact Inquiry via Message
Product Details
Input voltage:230V, 230VACweight:8-12kg
type:DC/AC inverterexhibit:LCD Monitor
payment terms:L/C,Western Union,D/P,D/A,T/T,MoneyGramInverter efficiency:97%
feature:Energy efficient solar inverters and hybrid invertersproduct name:Hybrid Solar Inverter
place of origin; place of origin:Zhejiang, Chinaoutput type:single
Waveform:pure sine waveEfficiency (peak) battery to INV.:93%
rated power:1-5KWsize:610mm*445mm*215mm
model:OEMWarranty:12 months
brand:OEMOutput current:60A/80A
Storage temperature:-15℃~60℃port:Ningbo
Efficiency (peak) PV to INV.:97%Transfer time:10ms (personal computer); 20ms (home application)
Operating temperature:0℃~55℃The output voltage:230V
Output frequency:50HZ/60HZ
Product Description
capacity
1.5KVA/1.5KW
3KVA/3KW
5KVA/5KW
5KVA/5KW
Parallel capability

Do not

Do not

Do not

Yes, 9 units
enter
standard
230VAC
acceptable voltage range
170-280 VAC (for personal computers), 90-280 VAC (for home appliances)
frequency
50/60HZ (automatic induction)
output
standard
220/230VAC ± 5%
surge power
3000VA
6000VA
10000VA
10000VA
frequency
50Hz/60Hz
waveform
pure sine wave
Transfer time
10ms (personal computer); 20ms (home appliances)
Peak Efficiency (PV to INV)
97%
Peak Efficiency (Cell to INV)

93%
Overload protection
5s@>=150% load; 10s 110%~150% load
Crest factor
3:1
allowable power factor
0.6~1 (inductive or capacitive)
Battery
Solar charging type
MPPT
maximum. PV array power
2000W
4000W
5000W
5000W
maximum. PV array open circuit voltage

500 VDC
PV array MPPT voltage range
120VDC~450VDC
Maximum solar input current

10A

15A

18A

18A
Maximum solar charging current

60A

80A

80A

80A
Maximum AC Charge Current

40A

60A

60A

60A
Maximum charging current

60A

80A

80A

80A
Communication Interface

USB/RS232/Dry Contact
surroundings
Operating temperature
(-10℃~50℃)
Storage temperature
(-15℃~60℃)
humidity
5% to 95% relative humidity (non-condensing)
nature
Size (L*W*H)
448mm*295mm*105mm
Package size (L*W*H)
565mm*380mm*190mm
Gross weight (kg)
8.5
9
10
10
communication method
USB/RS232/Dry Contact
detailed picture
