100A solar charge controller / charge controller for solar panel 80A 100A details
solar input max voltage:21V-42V;current:10A20A40A50A100A;
Packaging Detail:carton box packing for solar charger controlelr;N.W/G.W(kg):08.KG;
Single gross weight:38.0 KG;Selling Units:Single item;
Single package size:13.3X8.5X4 cm;Brand Name:Tanfon Solar;
Application:Solar System Controller;Battery Constant charge voltage(V):27/54;
Model Number:TC10A;Place of Origin:Guangdong China;
Type:PWM;accept OEM:yes;
Solar input charge protective voltage(V):28.6/57.2/114;working use:solar system or wind system;
Package size:240*138*82mm;packing:carton box packing;

100A solar charge controller / charge controller for solar panel 80A 100A

Company Information

 1) TANFON  has sold the system to Nigeria, Colombia, Burkina Faso, Egypt, Bolivia, Kenya, Ghana, South Africa, Argentina, Philippines, Congo, etc. Almost 85% of Africa countries !

2) With a professional installation team, Have went to Egypt,  Chad, Nigeria, Ghana, Doha, Pakistan for installation

3) Already started some inverter factories in some countries. so there is no problem in after sale service. And we are still looking for local factories in other countries, to unfolding depth of cooperation

4) We insist on using good quality raw material whenever and wherever.

5) With customer’s’ praise as an assurance,Tanfon is a guaranteed brand.

6) Our company's philosophy is: one-stop solar energy service platform





TANFON mainly manufacture all kinds of inverters, controller, solar system.

Solar system, have off grid and on grid system, single phase and three phase system, protable DC solar system etc.,

Inverter: pure sine wave, inverter&solar hybrid inverter, single phase&three phase, off grid&on grid.

Solar controller: PWM, MPPT

The various types of systems to meet the diverse needs of customers. Any interest, please send inquiry to us to get more details.



Product Description

Controller Features



 Our MPPT controller which represents advanced technology. The features are listed below:

  •    12V/24V auto recognition.
  •    Advanced maximum power point tracking technology to optimize using the solar system.
  •    Peak conversion efficiency of 95%, high Tracking efficiency of 97%.
  •    Very fast sweeping of the entire I-V curve several seconds tracking speed.
  •    Widely used, automatic recognize day/night.
  •    Timer function with 1-17 hours option for street light system.
  •     Unique dual timer function, enhance the flexibility of street light system.
  •     Sealed, Gel and Flooded battery be suitable.
  •     Adopting temperature compensation and correcting the charging and discharging parameters automatically, improving the battery lifetime.
  •      Electronic protection: over charging, over discharging ,overload short circuit.
  •      Reverse protection: any combination of solar module and battery, without causing damage to any component.
  •      Excellent thermal design and nature air cooling.



1 --  Charging Status LED Indicator

2 --  Battery Status LED Indicator

3 --  Output DC power Status LED Indicator

4 --  Temperature Sensor

5 --  Setting Button for load work mode

6 --  LED Digital Display for the load work mode

7 --  Switch power supply connection terminals

8 --  Loading terminals for connection of load

9 --  Battery Terminals for Connection of batteries.

10 --  Solar Module Terminals for Connection of solar modules.



connect way:



Controller technical data

Model

CP10

CP20

CP30

CP40

CP60

CP80

CP100

Rated Charge current(A)

10

20

30

40

60

80

100

Rated DC voltage(V)

12/24

12/24/48/96

(optional)

12/24/

48/96

(optional)

48/96/192/

240/384

(optional)

48/96/192/220/

384

(optional)

48/96/120

192/240/384

(optional)

48/96/120

192/240/384

(optional)

Solar input

Max voltage(V)

42

21/42/

84/168

21/42/

84/168

84/168

84/168

 84/168

84/168

Battery

Over charge protective voltage(V)

28.6

28.6/57.2/114

28.6/57.2/114

57.2/114

57.2/114.4

 57.2/114.4

57.2/114.4

Over charge recover voltage(V)

13.7/27.4

13.7/27.4

13.7/27.4

27.4/54.8

27.4/54.8

 54.8/109.6

 54.8/109.6

Constant charge voltage(V)

13.5/27

13.5/27

13.5/27

27/54

54

 54/108

54/108

Over discharge alarm voltage(V)

10/20

10/20

10/20

20/40

20/40

 40/80

40/80

Others

Environment Humidity and temperature

0-90% No condense,55℃

Protective Functions

Protection against anti-charge at night,battery over charge,over discharge protection,Joint-reversed of solar modules

Control method

PWM

Size :D*W*H(mm)

121*78*30

155*145*67

216*203*107

 216*203*107

216*203*107

417*360*118

Package:D*W*H(mm)

133*85*40

193*180*117

250*220*120

 250*220*120

250*220*120

440*420*200

N.W/G.W(kg)

0.2/0.3

0.9/1.1

2.5/2.8

 2.5/2.8

2.5/2.8

8.4/9.75





Solar system projects:









Customers feedback:









FAQ

Q1. what your company manufacturer?

A:all kinds solar inverter ,solar controller ,single phase and three phase pure sine wave inverter ,solar inverter with controller built-in ,solar inverter ,controller battery all in one box design .



Q2. what is the charge controller warranty?

A: for used solar system, we suggest buy solar inverter built-in controller, this warranty is 2 years.



Q3. what is the charge controller service?

A:ship the free PCB parts by DHL for service



Q4. what is the charge controller produce time

A: less than 100 pcs have stock !



Q5. What kind of certificate you have ?

Our company already achieve CE, RoHS. Any certificate can apply for you.



Q6. What is OEM?

Original Equipment Manufacturer.





Q7. How to pay for solar controller?

We accecpt paypal, western union, T/T. If you have any good payment, we also can accept.



We accept OEM and small trial orders, contacting with us now for more information. All inquiries will be replied with in 24 hours.
