Mini Grape Wine Membrane Filter

Supplier: Henan Shuangfa Chemical Industry Machinery Co., Ltd.
Region: Henan, China
Contact: Mr Alex Zhang
Price: $150.00 /set
Min. Order: 1 set

Click here to contact

Product details

Port:	Shanghai, Qingdao, Tianjin, etc;	Processing:	Filter;
Weight:	wine membrane filter;	Voltage:	220V/380V;
Processing Types:	Wine;	Payment Terms:	L/C,D/A,D/P,T/T,Western Union,MoneyGram,wine membrane filter;
Brand Name:	Shuangfa;	Local Service Location:	none;
Applicable Industries:	Food & Beverage Factory,Grape wine industry;	Quantity of Membrane Filter Core:	3pcs, wine membrane filter;
Condition:	New;	Warranty:	1 Year;
After-sales Service Provided:	Field installation, commissioning and training;	Model Number:	M10-3;
Filter accuracy:	0.22micron, 0.45micron;	Material:	304 Stainless Steel;
Application:	Wine Filtration, Sterilization filtration;	Supply Ability:	1000 Set/Sets per Month wine membrane filter;
Filter level:	3;	Capacity:	200-300kg/h;
Place of Origin:	Henan China;	Packaging Detail:	Wooden box grape wine membrane filter;
Name:	Grape wine membrane filter;	After Warranty Service:	Video technical support,Online support,Spare parts,Field maintenance and repair service;
Material of Membrane Filter Core:	PP;	Power:	60;
Operation:	Simple operation, moveable;	Showroom Location:	none;
Dimension(LWH):	wine membrane filter;	Certification:	CE, ISO9001;

Mini Grape Wine Membrane Filter

Introduction of Grape Wine Membrane Filter:

This machine can be used for liquid filtration of liquors such as liquor, rice wine and wine. The filtration accuracy can range from 0.22 μm to 5 μm.

Filter elment: The rear filter element is selected for 0.22um pore size fine filter for sterilization.

The front filter element can be used with a 1-5um pore size filter to remove particles in the liquid, and larger ions and impurities of microorganisms and bacteria.

Structure of Grape Wine Membrane Filter:

Features of Grape Wine Membrane Filter:

1, 304 stainless steel bottom plate, strong and durable, easy to clean.
2. Adopt 1micron/5micron PP cotton and 0.22micron PP filter core were adopted to make the filter clearer and achieve better results.
3, Including self-priming pump, food grade material.

Application of Grape Wine Membrane Filter:

Technical Parameter of Grape Wine Membrane Filter:

Model	M5-2	M5-3	M10-2	M10-3
Capacity(kg/h)	100-200	100-200	200-300	200-300
Quantity of filter core(pcs)	2	3	2	3
Power(w)	60	60	60	60
Voltage	220V 50HZ single phase	220V 50HZ single phase	220V 50HZ single phase	220V 50HZ single phase
