Full Automatic PET Preform Production Line / Making Machine

Product details
Hydraulic:YUKEN (Taiwan);Type:Injection Blow Molding;
Capacity:according different models;Style:HORIZONTAL;
Voltage:According customers' request;Supply Ability:15 Set/Sets per Month of PET preform production line;
Model Number:ZSJ;Payment Terms:L/C,T/T,Western Union;
Automatic:YES;Control:PLC (SIMENS);
Port:shanghai for PET preform production line;Brand Name:king machine;
Opening Stroke:280mm~1000mm;Certification:CE,ISO,SGS,CE,ISO,SGS;
Products:PET preform / PE caps;Plastic Type:PP,PE,PET;
Delivery Detail:After receiving samples within 30 days;Mould:Hot runner;
Packaging Detail:wooden cases for Full Automatic PET Preform Production Line / Making Machine;Injection Weight:845g;
Place of Origin:Jiangsu China;Name:PET preform production line;
After-sales Service Provided:Engineers available to service machinery overseas;Processing:Injection moulding;
Power(W):35kw;Clamping Force:700KN~10000KN;
Injection Rate:245g/s;Condition:New;

Full Automatic PET Preform Production Line / Making Machine



Specification



Model

Clamping force

(KN)

Mold thickness

(mm)

Tie-bars

space(mm)

Heat power

(KW)

Oil pump motor

 power(KW)

Dimension

(mm)

Weight

(KGS)

KM-1000A

1000

150-400

385x350

7.6

11

4300x1500x1600

3400

KM-1320A

1320

150-420

410x375

8.2

13

4500X1600X1700

3900

KM-1400A

1400

150-420

428X386

8.2

13

4800X1600X1700

4200

KM-1650A

1650

170-440

455X425

8.2

15

5000X1600X1700

5000

KM-1800A

1800

180-470

480X460

11

15

5300X1600X1750

5500

KM-2050A

2050

190-470

490X464

11.6

17

5400X1600X1750

6000

KM-2300A

2300

200-510

510X510

11.6

18.5

5700X1800X2000

6500

KM-2600A

2600

200-550

554X554

15.5

25

6100X1700X1800

8000

KM-3000A

3000

220-600

580X580

15.5

25

6500X1800X1800

9000

KM-3400A

3400

270-650

640X640

17.5

30

6700X2000X1900

10800

KM-3850A

3850

280-680

680X680

17.5

30

7000X2200X2000

11500

KM-4500A

4500

280-710

720X720

20.5

37

7300X2300X2400

13800

KM-4800A

4800

280-750

750X720

23.4

15+25

8300X2200X2200

16300

KM-5200A

5200

290-780

770X740

28.1

18.5+25

8600X2200X2250

20000

KM-5800A

5800

290-810

800X774

28.1

18.5+30

8750X2200X2300

21800

KM-6500A

6500

350-860

860X819

37.1

25+30

9200X2200X2400

26000

KM-7500A

7500

400-960

961X961

40.9

30+37

10700X2300X2700

38000

KM-8500A

8500

400-980

1016X980

42.5

37+37

11000X2400X2750

45000

KM-11000A

11000

500-1150

1230X1105

63

128

14000X2900X4100

63000

KM-13000A

13000

600-1400

1350X1280

85.25

160

13200X3100X3600

76000























































Characteristic



1.Strengthen locking structure

Optimized special locking system to reach efficient and fast production

2.Centralized lubrication, reliable protection

Configuring rational centralized lubrication, providing more professional, better lubrication to make machine more cleaner.

3.Professional templates optimized design

Template by advanced finite element analysis software to optimize design, high rigidity, high strength, to meet the rapid impact conditions demand.

4.Powerful, friendly control system

Adopts professional controller and friendly interface, easy and fast operation, with good reliability.

5.New type screw driving system

Spline connection for screw and oil motor, smooth and reliable transmission, big transfer torque, easy disassembly.

6.Excellent injection performance

Double cylinder injection, entire floor-guided, reliable and stable.

7.Superior clamping system

Adopts optimized connection rod structure, faster and smoother operation.

8.New frame structure

Simple and generous appearance, machine body force reasonable and stronger.

9.Professional plasticizing system

Suitable for different types of plastic raw material with professional plasticizing and heating system, good plasticizing performance.

10High efficient powerful servo system optional

Power system adopts high pressure gear box and servo motor, rotary encoder, pressure transducer and servo amplifier to get system closed-loop control.



Product Display









Adopting Europe technology, hydraulic unit adopts proportional pressure and flow control, the pressure and the speed can be adjusted, stable movement curve and gentle shock, the computer is imported from Industry family. The LCD displaying screen with high clarity has Chinese and English language to use. Close-loop PID temperature control with the advantage of high precision. The operating table of the injection moulding machine have two safety, one is machine safety, another is electrical safety, that ensures the operators’ safety.





Product Detail



+

NO.

Parts Name

Brand

Origin

1

Hydraulic Motor

DAN DUN

Italy-China

2

Hydraulic Oil Pump

HIGH-TECH

Made in Taiwan

3

Proportional Hydraulic Valve

HUAYE

Made in China

4

Transducer

Gefran



Made in Italy

5

Sealing Rings

HALLITE

Made in USA

6

Reversal Hydraulic Valve

SUNNY

Made in USA

7

High-pressure Vitta

Barthez

Made in Portugal



8

Contactor

LG

Made in Korea

9

Air-break Switch

LG

Made in Korea

10

Computer

TECHMATION

Made in Taiwan

11

Limit Switch

OMRON

Made in China

12

Proximity Switch

SCHNEIDER

Made in China



CLAMPING UNIT





1.The design of equipment is logical, easily operation.

2.The automatic level is very high, the wage is very little.

3.Using famous imported hydraulic, electrical, sealing parts, the trouble is low.

4.No matter what the product’s outside or inside, they can get the best guarantee, the good products rate can be above 99%

5 LCD computer control with big display screen
6 Hydraulic double proportional valve
7 Hard chrome plated high tensile strength steel tie bars
8 Generous space for fitting large moulds
9 Large opening stroke
10 Two position transducers to control Clamping and Injection
11 Four stages of injecting, independent velocity and pressure control



 CONTROL UNIT



12 Hydraulic mould height adjustment device
13 Screw cold-start prevention device
14 Melt decompression control
15 Screw back pressure control
16 Multiple hydraulic ejection
17 Differential high speed clamping
18 Centralized lubrication system
19 Low pressure mould protection device
20 Mechanical safety interlock
21 Double electrical safety interlock
22 Oil return filter
23 Oil tank with inner stainless steel container



Packaging & Shipping



Application



We can produce various kinds of injection moulding machine and different kinds of mould according to customer's requirement ,especially.

1.Mineral water bottle peform mould

2.Beverage bottle cap mould

3.5gallon cap mould

4.Theft poof, shampoo, oil, and sport cap mould

5.Cosmetics cap and wine mould

6.Box crane mould pvc fitting and switch mould and spoon fork and other mould



Company Information

Our Workshop



Our Team







Zhangjiagang King Machine Co., Ltd,is a direct manufacturer and exporter specializing in water treatment plants, beverage filling machine, packing machine, bottle blowing machine, injection   moulding machine and spare parts of filling line.

Our factory was established in the year of 1995, with the long history of accumulated experience in filling machine industry in south Jiangsu. There are many development engineer of filling machine in our company. We devote ourselves to the development, research and production of liquid food and beverage packing and filling industry.

King Machine cooperated with many customers in recent years, we win the trust of customers from our high-quality products. And we are looking forward to the future cooperation with you if our products can impress you deeply.
