Small Manufacturing Machines Toilet Tissue Paper Making Machine And Production Line

Supplier: Zhengzhou Mayjoy Import & Export Co., Ltd.
Region: Henan, China
Contact: Ms Danielle Ren
Price: $7500.00 /set
Min. Order: 1 set

Click here to contact

Product details

Working speed:	50-180m/min;	After-sales Service Provided:	Free spare parts,Video technical support,Online support;
Processing Type:	Paper Slitting and Rewinding Machine;	Package Preview:	https://sc02.alicdn.com/kf/HTB14rTxbRCw3KVjSZFlq6AJkFXaC.jpg_640x640.jpg,https://sc02.alicdn.com/kf/HTB1TXLdcBWD3KVjSZKPq6yp7FXa1.jpg_640x640.jpg;
Production Capacity:	500sets/Year;	Finished Products:	Toilet roll paper;
Application:	Paper Industry;	Voltage:	380V;
Product Type:	Toilet Tissue;	Dimension(LWH):	6000-7500mm2600-3200mm1750mm;
Place of Origin:	Henan China;	Weight:	2500-3500KG;
Power(W):	9KW;	Port:	Qingdao;
Condition:	New;	Type:	Paper Producton Line;
Embossing unit:	Wool Roller/Rubber Roller/Steel Roller;	Name:	Toilet Paper Machine;
Brand Name:	MAYJOY;	Automation:	Full-Atuomatic;
Color:	Customized Color;	Function:	Rewinding --Embossing--Perforating--Cutting--Packing;
Supply Ability:	250 Set/Sets per Month;	Packaging Detail:	Plywood Case or in Proper Way;
Warranty:	1 YEAR;	Capacity:	5T/D;
Payment Terms:	L/C,T/T,Western Union,MoneyGram;	Certification:	CE;
Applicable Industries:	Manufacturing Plant;

Small Manufacturing Machines Toilet Tissue Paper Making Machine And Production Line

Product Description

Small Manufacturing Machines Toilet Tissue Paper Making Machine And Production Line is used for rewinding jumbo paper to smaller roll, ready for cutting in next cutting step. It can automatically gluing, cutting when roll finished, has synchronous transmission system. Our machine can load three roll (three layers) the the same time. Pneumatic paper loading system is equipped to save human labor.

Model	Automatic toilet paper making machine
Jumbo Roll Max Width	1575mm/1760mm/1880mm (Customized is acceptable)
Jumbo Roll Diameter	Φ1200mm(Customized is acceptable)
Jumbo Roll Inner Diameter	3inches(76.2mm) (Customized is acceptable)
Perforation Distance	2-4 Screw Blades(100-150mm) (Customized is acceptable)
Finished Product Diameter	Φ40~φ200mm
Finished Product Core Diameter	φ38~φ48mm
Production Speed	150~280m/min
Program Controller	PLC Control, Variable frequency speed control, Touch screen operation
Unwind Stands	3 Stands(According to your requirment)
Pneumatic System	3HP Air Compressor, Minimum Pressure: 5kg/cm 2Pa(Provide by user)
Total Power	11KW 380V 50HZ
Dimension	6200-7500mm2600-3200mm1750mm(LWH)
Weight	About 3000KG
Edge-Line Embossing	Steel to Steel (Pneumatic Control)
Full Embossment	Steel to Rubber.
Rewinding Unit	With Core or Coreless

Packaging & Shipping

Our Services

1. Quality guarantee

We are not only selling machines, also provide you the most satisfying after-sale service. We will, without charge, offer replacement for defective parts which is caused on product quality in one year. Lifelong service is offered with cost charge after one year.

2.Packaging & Shipping

We can help you to arrange shipment by Sea, by Air or by Express. We also accept customer inspection on the goods before delivery.
The goods will be packed in standard export wooden case or if in large quantity, in 20 feet or 40 feet container.

3. Overseas Service

Our engineer can go to your workshop for installation and maintenance by customer's requirement.
