High Quality Paper Cup Production Making Machine Price,paper Cup Making Machine

Product details
Payment Terms:L/C,Western Union,D/P,D/A,T/T,MoneyGram;Marketing Type:New Product 2020;
Condition:New;After Warranty Service:Video technical support;
Paper Cup Size:2 ~16 OZ;Packaging Detail:Wooden Case: 2800*1300*1700MM;
Product Type:Paper Cup Machine;Cup Side Welding:Copper Heater;
Warranty of core components:1 Year;Showroom Location:None;
Core Components:PLC,Pressure vessel,Engine,Gear,Motor,Pump,Bearing,Gearbox,Other;Weight:1700 kg;
Video outgoing-inspection:Provided;GW:1800KGS;
Voltage:220/380V;Suitable paper weight:140~350gsm.;
Rated Productivity:75-85pcs/min;Warranty:1 year,1 Year;
Working Air Source:No need provide Air;NW:1700KGS;
Dimension(L*W*H):2100*970*1700mm;Power:4.KW;
Port:Ningbo or other ports;Brand Name:Mingyuan;
Machinery Test Report:Provided;Production Capacity:75-85pcs/min;
Place of Origin:Zhejiang, China;Processing Type:Paper Folding Machine;
Applicable Industries:Manufacturing Plant,Food & Beverage Factory,Printing Shops,Food & Beverage Shops;Supply Ability:30 Sets per Month;
Model
High Speed Single Plate Open Cam Paper Cup Machine JBZ-OCM12
Paper Cup Size:
2 ~16 OZ (Mould exchangeable, Max Cup Height:135mm , Max Bottom width :70mm
Rated Speed:
75-85pcs/min ( Speed affected by cup size, paper quality & thickness), 9OZ, 280GSM paper cup Stable running speed 80 pcs each min.
Raw Material:
Only one-side PE coated paper ( Popular for Hot drink cups )
One or Two side PE coated Paper
(Popular for Hot and Cold drink Cups)
Suitable paper weight:
140~250gsm
140-350gsm
Power Source:
50/60HZ, 380V/220V ( better use 380V, 3 Phase ) or special Power
requirement.
Total Power:
4 KW
6KW
Total Weight:
GW/NW: 1800KGS/1700KGS
Pack Size (L*W*H)
2100*970*1700mm(Machine Packing Size), 1250*860*1860MM(Counting Machine Packing Size)
Working Air Source:

No need provide Air
Air pressure:0.4Mpa;
Air Out-put:0.6m³/minute
Need to buy Air Compressor(by user)
Cup Side Welding:
Copper Heater
Ultrasonic heater
Cup Bottom Heating:
Heater Knurling
1side PE paper by heater knurling;
2side PE paper by cool device (circle
water) knurling.
Cup Bottom Knurling:
Heater Knurling (if use single PE coated paper)
OEM ( Show Client Company Name in Machine Panel ) is welcome in our factory
Main Technical Improve
Adopt Open Cam for the dividing moving, compare with index gearbox,easy maintenance, stable and reliable, easy replace broken parts.
Main mechanism and moving parts are controlled by quality gears, which is more efficient and more stronger than chain and axis.
Intelligent Model Bottom paper feeding controlled by Servo motor and Step Motor
which is high precision and high efficiency to support machine stable feeding bottom
paper .
Intelligent Model Using PLC control and touch screen.
If you need more information, please click here to consult us! ! !
Using famous brand motors, the quality of accessories is guaranteed!
1 1 year warranty service.
2 Free replacement of parts within 1 year (free shipping).
3 Parts are provided free of charge within 2 years, but no free shipping.
Remote guidance, save your time!
1 We provide Operation & Maintenance CD.
2 When there is a problem with the machine, please take a video of the problem and send it to us.
3 We will arrange professionals to help you deal with it through video or document tutorials.
Q1. Are you trading company or manufacturer?
A:we are one of the leading manufacturer of the paper cup machine, Plastic lid machine, paper plate machine etc paper product
machinery in China.

Q2. Do you have quality certificate?
A:we have got the ce certificate for our machine.

Q3. What's the delivery time?
A:Around 20~30 days, however, based on order.

Q4. where is your factory location?
A:we are locate in Henghe industrial zone, feiyun street, ruian city, zhejiang province, china. our nearest high way exit is
feiyun, our nearest train station is ruian station, our nearest airport is wenzhou airport.

Q5.How does your factory do regarding quality control?
A:Quality is priority. Our Factory always attach great importance to quality controlling from the very beginning to the very end:
1).Skilful workers care every details in handling the producing and packing processes;
2).Quality Control Department specially responsible for quality checking in each process.

Q6. What terms of payment you usually use?
A:T/T 30% deposit and 70% before machine loading, Western Union, L/C at sight.
