Automatic Copper wire cutting and stripping machine / cable peeling machine

Click here to contact

Product details

Productivity:	80 pcs/m;	Supply Ability:	20 Piece/Pieces per Week;
Driving way:	four-wheel drive , independent drive box driver;	Usage:	stripping ,cutting;
cutting tolerance:	within 0.002*L(L=cutting length);	Model Number:	HC-515A;
Power:	220 V /260 W;	Packaging Detail:	wooden case;
Brand Name:	hechang;	Package Preview:	https://sc01.alicdn.com/kf/HTB1MeAEQIfpK1RjSZFOq6y6nFXaY.jpg_640x640.jpg;
Size:	418X358X308 mm;	Stripping range:	PVC , glass wire;
Weight:	25 kg;	Cutting length:	1-99999.99mm;
Place of Origin:	Jiangsu China;	Stripping length:	0.5mm~30mm;
Payment Terms:	L/C,D/A,D/P,T/T,Western Union,MoneyGram,Paypal;	Max conduit diameter:	5 mm;
Port:	shanghai port;

Product Description

Click for more information !!!

Pay attention:

If your machine doesn't work completely in 5 years , we will change a new one for you!!!

Description

The compact body provides an optimum speed for mass production and ensures a high lever of productivity.

A very high performance even in a small-scale production of many diversified of wires.

HC-515A Model Suited for under 3 square of electric wire all cutting ,stripping

Feature:

Exceptional price to performance ratio

Intuitive, flexible and simple User-friendly english operation

Extremely low maintenance

Light and portable

Technical Data

Model	HC-515A
Outer dimensions	L452mmW380mmH435mm
Weight	30kg
Power supply	220V
Power consumption(220V)	400W
Cutting length	0.1mm--99999.99mm
Cutting tolerances	±( 0.1+0.0005×L )mm L : indicates a cutting length.
Stripping length	0.5mm--30mm
Applicable wires	PVC and Teflon wire, glass wire,1015,1017,PVC,XPL spring wire,RG174 ,etc
	Size	3 mm2 (AWG13--AWG28)
Wire feed speed	variable
Conduit diameter	1-5mm
Drive supply	four-wheels drive,independent drive box driver
Productivity(pcs/min)	80pcs/minute
